9 ENGLISH

Adjusting the fastening torque

►Fig.7: 1.Adjustingring2. Graduation 3.Arrow

Thefasteningtorquecanbeadjustedin21levelsbyturningtheadjustingring.Alignthegraduationswiththearrow

onthetoolbody.Youcangettheminimumfasteningtorqueat1andmaximumtorqueat

marking.

Theclutchwillslipatvarioustorquelevelswhensetatthenumber1to20.Theclutchdoesnotworkatthe marking.

Beforeactualoperation,driveatrialscrewintoyourmaterialorapieceofduplicatematerialtodeterminewhich

torque level is required for a particular application.

Thefollowingshowstheroughguideoftherelationshipbetweenthescrewsizeandgraduation.

Graduation 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20

Machine screw M4 M5 M6

Wood

screw

Soft wood

(e.g. pine)

– ø3.5 x 22 ø4.1 x 38

Hard wood

(e.g. lauan)

– ø3.5 x 22 –

– ø4.1 x 38

ASSEMBLY

CAUTION: Always be sure that the tool is

switched o󰀨 and the battery cartridge is removed

before carrying out any work on the tool.

Installing or removing driver bit/drill bit

For Model DF333D (optional accessory)

►Fig.8: 1. Sleeve 2. Close 3. Open

Turnthesleevecounterclockwisetoopenthechuckjaws.

Placethedriverbit/drillbitinthechuckasfarasitwillgo.

Turn the sleeve clockwise to tighten the chuck. To remove

thedriverbit/drillbit,turnthesleevecounterclockwise.

Installing or removing driver bit/

socket bit

For Model DF033D (optional accessory)

►Fig.9

Useonlydriverbit/socketbitthathasinsertingportion

showninthegure.Donotuseanyotherdriverbit/

socketbit.

NOTE:Bothshallowertype(A=12mm,B=9mm)and

deepertype(A=17mm,B=14mm)ofdriverbitscan

beused.

Toinstallthedriverbit,pullthesleeveinthedirectionof

thearrowandinsertthedriverbitintothesleeveasfar

as it will go.

Thenreleasethesleevetosecurethedriverbit.

►Fig.10: 1.Driverbit2. Sleeve

Toremovethedriverbit,pullthesleeveinthedirection

ofthearrowandpullthedriverbitout.

NOTE:Ifthedriverbitisnotinserteddeepenough

into the sleeve, the sleeve will not return to its original

positionandthedriverbitwillnotbesecured.Inthis

case,tryre-insertingthebitaccordingtotheinstruc-

tionsabove.

NOTE:Afterinsertingthedriverbit,makesurethatit

isrmlysecured.Ifitcomesout,donotuseit.

Installing hook

CAUTION: When installing the hook, always

secure it with the screw rmly. If not, the hook

maycomeo󰀨fromthetoolandresultinthepersonal

injury.

►Fig.11: 1. Groove 2. Hook 3. Screw

Thehookisconvenientfortemporarilyhangingthetool.

Thiscanbeinstalledoneithersideofthetool.Toinstall

the hook, insert it into a groove in the tool housing on

either side and then secure it with a screw. To remove,

loosen the screw and then take it out.

Installing driver bit holder

Optional accessory

►Fig.12: 1.Driverbitholder2.Driverbit

Fitthedriverbitholderintotheprotrusionatthetoolfoot

on either right or left side and secure it with a screw.

Whennotusingthedriverbit,keepitinthedriverbit

holders.Driverbits45mm-longcanbekeptthere.

OPERATION

CAUTION: Always insert the battery cartridge

all the way until it locks in place.Ifyoucanseethe

redindicatorontheuppersideofthebutton,itisnot

lockedcompletely.Insertitfullyuntiltheredindicator

cannotbeseen.Ifnot,itmayaccidentallyfalloutof

thetool,causinginjurytoyouorsomeonearound

you.

CAUTION: When the speed comes down

extremely, reduce the load or stop the tool to

avoid the tool damage.

Holdthetoolrmlywithonehandonthegripandthe

otherhandonthebottomofthebatterycartridgeto

control the twisting action.

►Fig.13
