- 15 -
& Vcore Voltage Mode/CPU Vcore/Dynamic Vcore(DVID)/BCLK Adaptive Voltage/CPU
Graphics Voltage (VAXG)/L2Atom Override Mode/Internal L2Atom/Internal L2Atom
Offset/Internal VCCSA/CPU VCCIN AUX/DRAM Vdd/VddQ/VCC1P05/VDD2 CPU/V0P82
PCH/V1P8 CPU/VCC1V8P
These items allow you to adjust the CPU Vcore and memory voltages. The displayed items and values
may vary depending on motherboard chipset and the CPU used.
