- 16 -
Advanced Voltage Settings
This submenu allows you to congure Load-Line Calibration level, over-voltage protection level, and over-
current protection level.
DDR5 Voltage Control
These items allow you to adjust DDR5 memory voltages. This submenu is only present on models that
support DDR5 memory.
