- 9 -
2-2 ProductSpecications
CPU LGA1700 socket: Support for 13th Generation Intel
®
Core
™
Processors and
12th Generation Intel
®
Core
™
, Pentium
®
Gold and Celeron
®
Processors
(Go to GIGABYTE's website for the latest CPU support list.)
L3 cache varies with CPU
Chipset Intel
®
Z690 Express Chipset
Memory Support for DDR5 4800/4000 MT/s memory modulesj
Support for DDR4 3200/3000/2933/2666/2400/2133 MT/s memory modulesk
2 x DDR DIMM sockets supporting up to 64 GB (32 GB single DIMM capacity)
of system memory
Dual channel memory architecture
Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in
non-ECC mode)
Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
Support for Extreme Memory Prole (XMP) memory modules
(Go to GIGABYTE's website for the latest supported memory speeds and memory
modules.)
Onboard
Graphics
Integrated Graphics Processor-Intel
®
HD Graphics support:
- 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz
* Support for HDMI 2.0 version and HDCP 2.3.
- 1 x DisplayPort port, supporting a maximum resolution of 5120x2160@60 Hz
* Support for DisplayPort 1.4 version and HDCP 2.3
* The DisplayPort does not support HDMI connection by adapter.
(Graphics specications may vary depending on CPU support.)
Audio Realtek
®
ALC4080 CODEC
Support for DTS:X
®
Ultra
High Denition Audio
2-channel
LAN Intel
®
2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps)
Wireless
Communication
Module
Intel
®
Wi-Fi 6E AX411
- WIFI a, b, g, n, ac, ax, supporting 2.4/5/6 GHz carrier frequency bands
- BLUETOOTH 5.2
- Support for 11ax 160MHz wireless standard and up to 2.4 Gbps data rate
* Actual data rate may vary depending on environment and equipment.
Expansion Slots 1 x PCI Express x16 slot, running at x16
(The PCI Express x16 slot conforms to PCI Express 5.0 standard.)
Storage Interface CPU:
- 1 x M.2 connector on the back of the GC-Z690I BTB PLUG (Socket 3, M key,
type 2260/2280 PCIe 4.0 x4/x2 SSD support) (M2A_CPU)
Chipset:
- 1 x M.2 connector on the front of GC-Z690I BTB PLUG (Socket 3, M key,
type 2242/2260/2280 PCIe 4.0 x4/x2 SSD support) (M2P_SB)
- 2 x SATA 6Gb/s connectorsj
- 4 x SATA 6Gb/s connectorsk
Support for RAID 0, RAID 1, RAID 5k, and RAID 10k
Intel
®
Optane
™
Memory Ready
* System acceleration with Intel
®
Optane
™
Memory can only be enabled on the M.2
connector supported by the Chipset.
j Only for Z690I AORUS ULTRA PLUS.
k Only for Z690I AORUS ULTRA PLUS DDR4.
