Gigabyte B660 GAMING X DDR4 [8/40] 2 product specifications
![Gigabyte B660 GAMING X [8/40] 2 product specifications](/views2/1919651/page8/bg8.png)
- 8 -
2-2 ProductSpecications
CPU LGA1700 socket: Support for 13th Generation Intel
®
Core
™
Processors and
12th Generation Intel
®
Core
™
, Pentium
®
Gold and Celeron
®
Processors
(Go to GIGABYTE's website for the latest CPU support list.)
L3 cache varies with CPU
Chipset Intel
®
B660 Express Chipset
Memory Support for DDR5 4800/4000 MT/s memory modules j
Support for DDR4 3200/3000/2933/2666/2400/2133 MT/s memory modules kl
4 x DDR DIMM sockets supporting up to 128 GB (32 GB single DIMM capacity)
of system memory
Dual channel memory architecture
Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in
non-ECC mode)
Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
Support for Extreme Memory Prole (XMP) memory modules
(Go to GIGABYTE's website for the latest supported memory speeds and memory
modules.)
Onboard
Graphics
Integrated Graphics Processor-Intel
®
HD Graphics support:
- 1 x DisplayPort, supporting a maximum resolution of 4096x2304@60 Hz
* Support for DisplayPort 1.2 version and HDCP 2.3
- 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz
* Support for HDMI 2.0 version and HDCP 2.3.
(Graphics specications may vary depending on CPU support.)
Audio Realtek
®
Audio CODEC
High Denition Audio
2/4/5.1/7.1-channel
Support for S/PDIF Out
LAN Realtek
®
2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps)
Wireless
Communication
Module
k
AMD Wi-Fi 6E RZ608 (MT7921K)
- WIFI a, b, g, n, ac, ax, supporting 2.4/5/6 GHz carrier frequency bands
- BLUETOOTH 5.2
- Support for 11ax 80MHz wireless standard and up to 1.2 Gbps data rate
(Actual data rate may vary depending on environment and equipment.)
Expansion Slots 1 x PCI Express x16 slot, running at x16 (PCIEX16)
* For optimum performance, if only one PCI Express graphics card is to be installed,
be sure to install it in the PCIEX16 slot.
(The PCIEX16 slot conforms to PCI Express 4.0 standard.)
2 x PCI Express x16 slots, running at x1 (PCIEX1_1, PCIEX1_2)
(All of the PCI Express slots conform to PCI Express 3.0 standard.)
j Only for B660 GAMING X.
k Only for B660 GAMING X AX DDR4.
l Only for B660 GAMING X DDR4.
