- 11 -
& Intel(R) Turbo Boost Technology
(Note)
Allows you to determine whether to enable the Intel
®
CPU Turbo Boost technology. Auto lets the BIOS
automatically congure this setting.
& Intel(R) Turbo Boost Max Technology 3.0
(Note)
Enables or disables Intel
®
Turbo Boost Max Technology 3.0. Intel
®
Turbo Boost Max Technology 3.0 allows
the system to identify the processor's best performance core and lets you manually direct the most critical
workloads to it. You can even adjust the frequency of each core individually for performance optimization.
& CPU Flex Ratio Override
Enables or disables the CPU Flex Ratio. The maximum CPU clock ratio will be based on the CPU Flex
Ratio Settings value if CPU Clock Ratio is set to Auto.
& CPU Flex Ratio Settings
Allows you to set the CPU Flex Ratio. The adjustable range may vary by CPU.
& Frequency Clipping TVB
(Note)
Allows you to enable or disable automatic CPU frequency reduction initiated by Thermal Velocity Boost.
Auto lets the BIOS automatically congure this setting.
& Voltage reduction initiated TVB
(Note)
Allows you to enable or disable automatic CPU voltage reduction initiated by Thermal Velocity Boost. Auto
lets the BIOS automatically congure this setting.
& IA CEP (Current Excursion Protection)
(Note)
Allows you to enable or disable IA CEP.
& GT CEP (Current Excursion Protection)
(Note)
Allows you to enable or disable GT CEP.
d AVX Settings
Allows you to congure AVX related settings. Auto sets the settings according to the CPU specications.
& AVX Disable
Allows you to disable the AVX instruction sets on a CPU that supports AVX. This item is congurable only
when AVX Settings is set to User Dened.
& AVX Offset
(Note)
When the processor runs AVX workloads, the CPU Clock Ratio will be reduced by the desired AVX offset
value. For example, if the value is set to 3, the CPU Clock Ratio will be reduced by 3 when executing AVX
instructions.
& AVX Voltage Guardband Scale Factor
(Note)
Allows you to lower the standard AVX voltage.
d Active Turbo Ratios
& Turbo Ratio (Core Active)
Allows you to set the CPU Turbo ratios for different number of active cores. Auto sets the CPU Turbo ratios
according to the CPU specications. This item is congurable only when Active Turbo Ratios is set to
Manual.
(Note) This item is available only when the motherboard chipset and the CPU used support this feature.
For more information about Intel
®
CPUs' unique features, please visit Intel's website.
