Gigabyte Z590 UD AC [18/52] Note supported by 11th generation processors only
![Gigabyte Z590 UD AC [18/52] Note supported by 11th generation processors only](/views2/1919722/page18/bg12.png)
• M2A_SB:
SATA3 1 SATA3 2 SATA3 3 SATA3 4 SATA3 5
M.2 SATA SSD
r
a a a a
M.2 PCIe SSD
a a a a a
No M.2 SSD Installed
a a a a a
a: Available, r: Not available
Connector
Type of M.2
SSD
Installation Notices for the M.2 and SATA Connectors:
The availability of the SATA connectors may be affected by the type of device installed in the M.2 sockets. The
M2A_SB connector shares bandwidth with the SATA3 1 connector. Refer to the following tables for details.
• M2M_SB:
SATA3 1 SATA3 2 SATA3 3 SATA3 4 SATA3 5
M.2 PCIe SSD *
a a a a a
No M.2 SSD Installed
a a a a a
a: Available, r: Not available
* The M2M_SB connector supports only PCIe SSDs.
Connector
Type of M.2
SSD
• M2P_CPU
(Note):
SATA3 1 SATA3 2 SATA3 3 SATA3 4 SATA3 5
M.2 PCIe SSD
a a a a a
No M.2 SSD Installed
a a a a a
a: Available, r: Not available
* The M2P_CPU connector supports only PCIe SSDs.
Connector
Type of M.2
SSD
(Note) Supported by 11th Generation processors only.
- 18 -
