1-2 ProductSpecications
CPU AMD Socket AM4, support for:
AMD Ryzen
™
5000 Series Processors/
AMD Ryzen
™
5000 G-Series Processors/
AMD Ryzen
™
4000 G-Series Processors/
AMD Ryzen
™
3000 Series Processors
(Go to GIGABYTE's website for the latest CPU support list.)
Chipset AMD B550
Memory 2 x DDR4 DIMM sockets supporting up to 64 GB (32 GB single DIMM capacity)
of system memory
Support for DDR4 3200/2933/2667/2400/2133 MHz memory modules
Dual channel memory architecture
Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules
Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
Support for Extreme Memory Prole (XMP) memory modules
(Go to GIGABYTE's website for the latest supported memory speeds and memory
modules.)
Onboard
Graphics
Integrated in the AMD Ryzen
™
5000 G-Series/4000 G-Series Processors:
- 1 x D-Sub port, supporting a maximum resolution of 1920x1200@60 Hz
- 1 x DVI-D port, supporting a maximum resolution of 1920x1200@60 Hz
* The DVI-D port does not support D-Sub connection by adapter.
- 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz
* Support for HDMI 2.1 version, HDCP 2.3, and HDR.
Support for up to 3 displays at the same time
Maximum shared memory of 16 GB
Audio Realtek
®
Audio CODEC
High Denition Audio
2/4/5.1/7.1-channel
* To congure 7.1-channel audio, you need to open the audio software and select Device
advanced settings > Playback Device to change the default setting rst. Please visit
GIGABYTE's website for details on conguring the audio software.
LAN Realtek
®
GbE LAN chip (1 Gbps/100 Mbps)
Expansion Slots 1 x PCI Express x16 slot, integrated in the CPU:
- AMD Ryzen
™
5000 Series/3000 Series Processors support PCIe 4.0 x16 mode
- AMD Ryzen
™
5000 G-Series/4000 G-Series Processors support PCIe 3.0 x16
mode
* For optimum performance, if only one PCI Express graphics card is to be installed,
be sure to install it in the PCIEX16 slot.
2 x PCI Express x1 slots (PCIEX1_1, PCIEX1_2), integrated in the Chipset:
- Supporting PCIe 3.0 x1 mode
Storage Interface 1 x M.2 connector, integrated in the CPU, supporting Socket 3, M key,
type 2242/2260/2280 SSDs:
- AMD Ryzen
™
5000 Series/3000 Series Processors support SATA and PCIe 4.0
x4/x2 SSDs
- AMD Ryzen
™
5000 G-Series/4000 G-Series Processors support SATA and
PCIe 3.0 x4/x2 SSDs
4 x SATA 6Gb/s connectors, integrated in the Chipset:
- Support for RAID 0, RAID 1, and RAID 10
- 6 -
