Gigabyte GA-A520I-DASH [30/38] Chipset sata port 0 1

& SATA Mode

Enables or disables RAID for the SATA controllers integrated in the Chipset or congures the SATA controllers

to AHCI mode.

RAID Enables RAID for the SATA controller.

AHCI Congures the SATA controllers to AHCI mode. Advanced Host Controller Interface

(AHCI) is an interface specication that allows the storage driver to enable advanced

Serial ATA features such as Native Command Queuing and hot plug. (Default)

& NVMe RAID mode

Allows you to determine whether to use your M.2 NVMe PCIe SSDs to congure RAID. (Default: Disabled)

& Chipset SATA Port Enable

Enables or disables the integrated SATA controllers. (Default: Enabled)

& Chipset SATA Port 0/1

Displays the information of the connected SATA device(s).

- 30 -
