Gigabyte GA-A520I-DASH [4/38] Box contents

CPU_FAN

SYS_FAN1

GA-A520I-DASH

AUDIO

DDR4_1

BAT

AMD

A520

HDMI

CODEC

M_BIOS

DUAL DP

PCIEX16

iTE

Super I/O

Realtek

GbE LAN

F_U32

COMB

F_PANEL

SATA3

0 1

DC_PWR

Socket AM4

CLR_CMOS

M2A_CPU

80 60

DDR4_2

F_AUDIO

USB30_

LANA

LANB

SPEAKER

F_USB1

F_USB2

COMA

SATA_PWR1

SPKR

TPM

Realtek

GbE LAN

- 4 -

GA-A520I-DASH Motherboard Layout

* The box contents above are for reference only and the actual items shall depend on the product package you obtain.

The box contents are subject to change without notice.

Box Contents

5 GA-A520I-DASH motherboard 5 I/O Shield

5 Motherboard driver disc 5 One COM port cable

5 User's Manual 5 One SATA power cable

5 Two SATA cables

Temperature sensor
