PRIME / ProArt / TUF GAMING Intel 700 Series BIOS Manual
35
The following items appear only when SA GV is set to [Enabled], [Fixed to 1st Point],
[Fixed to 2nd Point], [Fixed to 3rd Point], or [Fixed to 4th Point].
First Point Frequency
Allows you to specify the frequency for the given point. 0-MRC auto, else a specific
frequency as an integer: 2000Mhz.
Configuration options: [0] - [65535]
First Point Gear
Allows you to set the gear ratio for this SAGV point. 0-Auto, 1-G1, 2-G2, 4-G4.
Configuration options: [0] - [4]
Second Point Frequency
Allows you to specify the frequency for the given point. 0-MRC auto, else a specific
frequency as an integer: 2000Mhz.
Configuration options: [0] - [65535]
Second Point Gear
Allows you to set the gear ratio for this SAGV point. 0-Auto, 1-G1, 2-G2, 4-G4.
Configuration options: [0] - [4]
Third Point Frequency
Allows you to specify the frequency for the given point. 0-MRC auto, else a specific
frequency as an integer: 2000Mhz.
Configuration options: [0] - [65535]
Third Point Gear
Allows you to set the gear ratio for this SAGV point. 0-Auto, 1-G1, 2-G2, 4-G4.
Configuration options: [0] - [4]
The Fourth Point Gear will always be the settings you set in the main menu, so configure
the Fourth Point Gear there.
Digi+ VRM
CPU Input Voltage Load-line Calibration
Configuration options [Auto] [Level 1] [Level 2] [Level 3]
CPU Load-line Calibration
The load-line is defined by the Intel VRM specification and affects the level of voltage
supplied to the processor. Higher load-line calibration settings result in reduced
VDroop at the expense of voltage overshoot and will increase CPU temperatures due
to higher voltage under load. Select from level 1 to 7 to adjust the load-line slope.
Level 1 = greater VDroop, Level 7 = minimum VDroop.
Configuration options [Auto] [Level 1] [Level 2] [Level 3] [Level 4:Recommended for
OC] [Level 5] [Level 6] [Level 7]
The actual performance boost may vary depending on your CPU specification.
DO NOT remove the thermal module. The thermal conditions should be monitored.
Synch ACDC Loadline with VRM Loadline
Enable this item to allow the VRM Loadline to be adjusted automatically to match the
AC/DC Loadline.
Configuration options: [Disabled] [Enabled
