PRIME / ProArt / TUF GAMING Intel 700 Series BIOS Manual
Memory Configuration
The items in this submenu allow you to set memory configuration parameters.
Memory Remap
Allows you to enable or disable memory remap above 4GB.
Configuration options: [Enabled] [Disabled]
Graphics Configuration
The items in this submenu allow you to select a primary display from CPU Graphics, PEG
Graphics devices, or PCIe Graphics devices.
Primary Display
Allows you to select the primary display from CPU Graphics / PEG Graphics / PCIe
Graphics device.
Configuration options: [Auto] [CPU Graphics] [PEG Slot] [PCIE]
iGPU Multi-Monitor
Set this item to [Enabled] to empower both integrated and discrete graphics for multi-
monitor output. iGPU shared system memory size will be fixed at 64M.
Configuration options: [Disabled] [Enabled]
DVMT Pre-Allocated
Allows you to select the DVMT 5.0 Pre-Allocated (Fixed) Graphics Memory size used
by the Internal Graphics Device.
Configuration options: [32M] [64M] [96M] [128M] [160M] [192M] [224M] [256M] [288M]
[320M] [352M] [384M] [416M] [448M] [480M] [512M]
RC6(Render Standby)
Allows you to enable render standby support.
Configuration options: [Disabled] [Enabled]
VMD setup menu
The items in this submenu allow you to set the VMD configuration settings.
Enable VMD controller
Allows you to enable or disable the VMD controller.
Configuration options: [Disabled] [Enabled]
Setting the Enable VMD controller to [Disabled] may result in data loss.
The following items appear only when Enable VMD controller is set to [Enabled].
Map PCIE Storage under VMD
Allows you to map or unmap PCIE Storage to VMD.
Configuration options: [Disabled] [Enabled]
Ensure to set Map SATA Controller under VMD to [Disabled] if you set Map PCIE
Storage under VMD to [Enabled].
