PRIME / ProArt / TUF GAMING Intel 700 Series BIOS Manual
23
The following items appear only when Performance Core0-5 specific Voltage is set to
[Adaptive Mode].
Offset Mode Sign
[+] Offset the CPU core voltage by a positive value.
[-] Offset the CPU core voltage by a negative value.
Additional Turbo Mode CPU Core0-5 Voltage
Configure the amount of voltage fed to the CPU cores when running in the turbo
mode. Increase the voltage when configuring a High CPU core frequency. This
voltage will be affected by the offset value. Use the <+> or <-> to adjust the value. The
values range from 0.001V to 1.920V with an interval of 0.001V.
Configuration options: [Auto] [0.00100] - [1.92000]
Performance Core0-5 Offset
Configure the CPU core voltage offset value. Use the <+> or <-> to adjust the value.
The values range from 0.001 V to 0.999 V with an interval of 0.001 V.
Configuration options: [Auto] [0.00100] - [0.99900]
You need to save the changes and reset the system for the changes to take effect.
Efficient Core Ratio
[Auto] The system will adjust all Efficient core ratios automatically.
[Sync All Cores] Configure a core ratio limit to synchronize all Efficient cores.
[By Core Usage] Configure the ratio limits for active cores depending on how many Efficient
cores are being utilized.
[AI Optimized] Use AI to optimize the Efficient core ratios.
• The [AI Optimized] item appears only when you use an unlocked CPU.
• The following item appears only when Efficient Core Ratio is set to [Sync All
Cores].
ALL-Core Ratio Limit
Ratio Limit for Efficient Cores when N Efficient cores are loaded. Use the <+> or <-> to
adjust the value.
Configuration options: [Auto] [8] - [85]
The following items appear only when Efficient Core Ratio is set to [By Core Usage].
Efficient 1-Core Ratio Limit / Efficient 2-Core Ratio Limit / Efficient 3-Core
Ratio Limit / Efficient 4-Core Ratio Limit / Efficient 5-Core Ratio Limit /
Efficient 6-Core Ratio Limit / Efficient 7-Core Ratio Limit / Efficient 8-Core
Ratio Limit
Ratio Limit for Efficient cores when N Efficient cores are loaded. Use the <+> or <-> to
adjust the value.
Configuration options: [Auto] [27] - [85]
