vii
ProArt Z790-CREATOR WIFI specifications summary
CPU
Intel
®
Socket LGA1700 for 13
th
Gen Intel
®
Core™ Processors & 12
th
Gen
Intel
®
Core™, Pentium
®
Gold and Celeron
®
Processors
Supports Intel
®
Turbo Boost Technology 2.0 and Intel
®
Turbo Boost Max
Technology 3.0**
* Refer to www.asus.com for CPU support list.
** Intel
®
Turbo Boost Max Technology 3.0 support depends on the CPU types.
Chipset
Intel
®
Z790 Chipset
Memory
4 x DIMM, Max. 128GB, DDR5 7200(OC) / 7000(OC) / 6800(OC) /
6600(OC) / 6400(OC) / 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600/ 5400/
5200/ 5000/ 4800MHz Non-ECC, Un-buffered Memory*
Dual Channel Memory Architecture
Supports Intel
®
Extreme Memory Profile (XMP)
OptiMem II
* Supported memory types, data rate(Speed), and number of DRAM module
vary depending on the CPU and memory configuration, for more information
refer to www.asus.com for memory support list.
Graphics
1 x HDMI
®
port**
2 x Intel
®
Thunderbolt™ 4 ports (USB Type-C
®
) support DisplayPort***
and Thunderbolt™ video outputs****
* Graphics specifications may vary between CPU types. Please refer to
www.intel.com for any updates.
** Support 4K@60Hz as specified in HDMI
®
2.1.
*** Support 8K@60Hz as specified in DisplayPort 1.4.
**** Output at TBT4_E1 and TBT4_E2, the USB Type-C
®
ports right under
RJ45 ports, each requires a USB-C
®
to DisplayPort adapter cable. VGA
resolution support depends on processors’ or graphic cards’ resolution.
Expansion Slots
Intel
®
13
th
& 12
th
Gen Processors*
2 x PCIe 5.0 x16 slots (support x16 or x8/x8 modes)
Intel
®
Z790 Chipset**
1 x PCIe 4.0 x16 slot (supports x4 mode)
* Please check the PCIe bifurcation table on support site
(https://www.asus.com/support/FAQ/1037507/).
To ensure compatibility of the device installed, please
refer to https://www.asus.com/support/ for the list of
supported peripherals.
Storage
Total supports 4 x M.2 slots and 8 x SATA 6Gb/s ports*
Intel
®
13
th
& 12
th
Gen Processors
M.2_1 slot (Key M), type 2242/2260/2280/22110
(supports PCIe 4.0 x4 mode)
(continued on the next page)
