English
1
B760 Pro RS
Chapter 1 Introduction
ank you for purchasing ASRock B760 Pro RS motherboard, a reliable
motherboard produced under ASRock’s consistently stringent quality control.
It delivers excellent performance with robust design conforming to ASRock’s
commitment to quality and endurance.
1.1 Package Contents
•
ASRock B760 Pro RS Motherboard (ATX Form Factor)
•
ASRock B760 Pro RS User Manual
•
2 x Serial ATA (SATA) Data Cables (Optional)
•
4 x Screws for M.2 Sockets (Optional)
•
1 x Stando for M.2 Socket (Optional)
Because the motherboard specications and the BIOS soware might be updated, the
content of this documentation will be subject to change without notice. In case any modi-
cations of this documentation occur, the updated version will be available on ASRock’s
website without further notice. If you require technical support related to this mother-
board, please visit our website for specic information about the model you are using. You
may nd the latest VGA cards and CPU support list on ASRock’s website as well. ASRock
website http://www.asrock.com.
