31
Intel Z790/H770/B760 Series
AVX2 Ratio Oset
AVX2 Ratio Oset species a negative oset from the CPU Ratio for AVX workloads. AVX
is a more stressful workload that lower the AVX ratio to ensure maximum possible ratio
for SSE workloads.
CPU E-Core Ratio
e E-Core speed is determined by the E-Core Ratio multiplied with the BCLK. Increasing
the E-Core Ratio will increase the internal E-Core clock speed without aecting the clock
speed of other components.
Conguration options: [Auto] [All Core] [Per Core] [Specic Per Core]
CPU Cache Ratio
e CPU Internal Bus Speed Ratio. e maximum should be the same as the CPU Ratio.
Min Cache Ratio
e CPU internal bus speed minimum ratio. To align cache ratio with P-Core ratio for
non-K CPU, you can try to sync Min Cache Ratio Limit with CPU Cache Ratio.
GT Frequency
Allows you to congure the frequency of the integrated GPU in MHz. is item appears
when you use the onboard graphics.
CPU Flex Ratio Override
Allows you to enable or disable CPU Flex Ratio Programming. Flex Ratio can lower
maximum non-turbo, especially for CPU without turbo function.
Conguration options: [Auto] [Enabled]
CPU Flex Ratio
is value must be between Max Eciency Ratio (LFM) and Maximum non-turbo ratio
set by Hardware (HFM).
BCLK Frequency
e CPU speed is determined by the CPU Ratio multiplied with the BCLK. Increasing the
BCLK will increase the internal CPU clock speed but also aect the clock speed of other
components.
PEG/DMI Frequency
Allows you to congure the PEG/DMI Frequency.
