45
Intel Z790/H770/B760 Series
ODT PARK (B2)
Congure the memory on die termination resistors' PARK.
Conguration options: [Auto] [34] [40] [48] [60] [80] [120] [240] [Disabled]
ODT PARK DQS (A1)
Congure the memory on die termination resistors' PARK DQS.
Conguration options: [Auto] [34] [40] [48] [60] [80] [120] [240] [Disabled]
ODT PARK DQS (A2)
Congure the memory on die termination resistors' PARK DQS.
Conguration options: [Auto] [34] [40] [48] [60] [80] [120] [240] [Disabled]
ODT PARK DQS (B1)
Congure the memory on die termination resistors' PARK DQS.
Conguration options: [Auto] [34] [40] [48] [60] [80] [120] [240] [Disabled]
ODT PARK DQS (B2)
Congure the memory on die termination resistors' PARK DQS.
Conguration options: [Auto] [34] [40] [48] [60] [80] [120] [240] [Disabled]
ODT CA (A1 Group A)
Congure the memory on die termination resistors' CA.
Conguration options: [Auto] [40] [60] [80] [120] [240] [480] [Disabled]
ODT CA (A2 Group A)
Congure the memory on die termination resistors' CA.
Conguration options: [Auto] [40] [60] [80] [120] [240] [480] [Disabled]
ODT CA (B1 Group A)
Congure the memory on die termination resistors' CA.
Conguration options: [Auto] [40] [60] [80] [120] [240] [480] [Disabled]
ODT CA (B2 Group A)
Congure the memory on die termination resistors' CA.
Conguration options: [Auto] [40] [60] [80] [120] [240] [480] [Disabled]
