ASRock H670M Pro RS [12/103] English
![ASRock H670M Pro RS [12/103] English](/views2/1921036/page12/bgc.png)
7
English
H670M Pro RS
No. Description
1 ATX 12V Power Connector (ATX12V1)
2 ATX 12V Power Connector (ATX12V2)
3 2 x 288-pin DDR4 DIMM Slots (DDR4_A1, DDR4_B1)
4 2 x 288-pin DDR4 DIMM Slots (DDR4_A2, DDR4_B2)
5 CPU/Water Pump Fan Connector (CPU_FAN2/WP)
6 CPU Fan Connector (CPU_FAN1)
7 RGB LED Header (RGB_LED1)
8 Addressable LED Header (ADDR_LED1)
9 ATX Power Connector (ATXPWR1)
10 Front Panel Type C USB 3.2 Gen1 Header (USB3_TC_1)
11 USB 3.2 Gen1 Header (USB3_7_8)
12 SATA3 Connector (SATA3_0)
13 SATA3 Connector (SATA3_1)
14 SATA3 Connector (SATA3_2) (Upper), SATA3 Connector (SATA3_3) (Lower)
15 System Panel Header (PANEL1)
16 SPI TPM Header (SPI_TPM_J1)
17 Chassis Intrusion and Speaker Header (SPK_CI1)
18 Post Status Checker (PSC)
19 USB 2.0 Header (USB3_4)
20 USB 2.0 Header (USB1_2)
21 USB 3.2 Gen1 Header (USB3_5_6)
22 Chassis/Water Pump Fan Connector (CHA_FAN2/WP)
23 Chassis/Water Pump Fan Connector (CHA_FAN3/WP)
24 Clear CMOS Jumper (CLRMOS1)
25 Addressable LED Header (ADDR_LED3)
26 Addressable LED Header (ADDR_LED2)
27 Front Panel Audio Header (HD_AUDIO1)
28 5-pin underbolt AIC Connector (TB1)
29 Chassis/Water Pump Fan Connector (CHA_FAN1/WP)
30 Chassis/Water Pump Fan Connector (CHA_FAN4/WP)
