64
English
Initial RTL FIF0 Delay Oset
Congure round trip latency FIF0 delay initial oset.
Initial RTL (MC0 C0 A1/A2)
Congure round trip latency initial value.
Initial RTL (MC0 C1 A1/A2)
Congure round trip latency initial value.
Initial RTL (MC1 C0 B1/B2)
Congure round trip latency initial value.
Initial RTL (MC1 C1 B1/B2)
Congure round trip latency initial value.
RTL (MC0 C0 A1/A2)
Congure round trip latency value.
RTL (MC0 C1 A1/A2)
Congure round trip latency value.
RTL (MC1 C0 B1/B2)
Congure round trip latency value.
RTL (MC1 C1 B1/B2)
Congure round trip latency value.
ODT Setting
Dimm ODT Training
ODT values will be optimized by Dimm On-Die Termination Training.
ODT WR (A1)
Congure the memory on die termination resistors' WR for channel A1.
ODT WR (A2)
Congure the memory on die termination resistors' WR for channel A2.
ODT WR (B1)
Congure the memory on die termination resistors' WR for channel B1.
ODT WR (B2)
