ASRock B650M PG Riptide [3/63] Chapter 1 introduction 1
![ASRock B650M PG Riptide [3/63] Chapter 1 introduction 1](/views2/1921122/page3/bg3.png)
Contents
Chapter 1 Introduction 1
1.1 Package Contents 1
1.2 Specications 2
1.3 Motherboard Layout 6
1.4 I/O Panel 8
1.5 Block Diagram 10
Chapter 2 Installation 11
2.1 Installing the CPU 12
2.2 Installing the CPU Fan and Heatsink 15
2.3 Installing Memory Modules (DIMM)
24
2.4 Connecting the Front Panel Header 26
2.5 Installing the Motherboard 27
2.6 Installing SATA Drives 28
2.7 Installing a Graphics Card 30
2.8 Connecting Peripheral Devices 32
2.9 Connecting the Power Connectors 33
2.10 Power On 34
2.11 Jumpers Setup 35
2.12 Onboard Headers and Connectors 36
2.13 Smart Switches 49
2.14 Post Status Checker 51
