3
B650M PG Riptide
LAN
•
2.5 Gigabit LAN 10/100/1000/2500 Mb/s
•
Dragon RTL8125BG
•
Supports Phantom Gaming LAN Soware
- Smart Auto Adjust Bandwidth Control
- Visual User Friendly UI
- Visual Network Usage Statistics
- Optimized Default Setting for Game, Browser, and
Streaming Modes
- User Customized Priority Control
USB
•
1 x USB 3.2 Gen2 Type-C (Rear)
•
1 x USB 3.2 Gen2 Type-A (Rear)
•
1 x USB 3.2 Gen1 Type-C (Front)
•
6 x USB 3.2 Gen1 (2 Rear, 4 Front)
•
8 x USB 2.0 (4 Rear, 4 Front)
* All USB ports support ESD Protection
Rear Panel
I/O
•
1 x HDMI Port
•
1 x DisplayPort 1.4
•
1 x USB 3.2 Gen2 Type-A Port (10 Gb/s) (ReDriver)
•
1 x USB 3.2 Gen2 Type-C Port (10 Gb/s) (ReDriver)
•
2 x USB 3.2 Gen1 Ports (USB32_23 are Lightning Gaming
Ports.)
•
4 x USB 2.0 Ports
•
1 x RJ-45 LAN Port
•
1 x BIOS Flashback Button
•
HD Audio Jacks: Line in / Front Speaker / Microphone
Storage
CPU:
•
1 x Blazing M.2 Socket (M2_1, Key M), supports type
2260/2280 PCIe Gen5x4 (128 Gb/s) mode*
Chipset:
•
1 x Hyper M.2 Socket (M2_2, Key M), supports type
2260/2280 PCIe Gen4x4 (64 Gb/s) mode*
•
4 x SATA3 6.0 Gb/s Connectors
* Supports NVMe SSD as boot disks
* Supports ASRock U.2 Kit
