Operation
You can set Refrigerator
temperature using the REF. TEMP.
button, whenever pressing the
button, the LED emit light. The
temperature of the compartment is
lowered as the LED luminance
from “Cold" to “Colder". You can
select the desired setting point five
steps
For the economic electricity, set
(from the Cold to the Colder).
Refrigerator
Temperature
Super Cool
When SUPER COOL button is
pressed, refrigerator goes to super
cool mode, and super cool icon will
ON. This function allows you to
gear up for any urgent cooling
needs. In this case, compressor
runs continuously for few hours
giving you cold water and ice when
Energy Saver
If you push the ENERGY
SAVER/CHILD LOCK key, your
refrigerator enters into Energy Save
mode and Energy Saver Icon will be
ON. Energy Saver mode facilitates
you to save energy while
maintaining uniform cooling for long
hours. It is recommended that once
you ensure that your refrigerator is
Child Lock
If you push the ENERGY
SAVER/CHILD LOCK key
continuously for 5 seconds, all
functions/settings of your
refrigerator will be locked if
previously unlocked and the
lock icon will be ON. During lock
mode your settings are not
subjected to change.
If you again push the same key
for 5 seconds, then all
refrigerator functions or settings
will be unlocked, lock icon will be
OFF and settings are subjected
to change.
Press this button for 5 seconds and
The CHILD LOCK lamp will turn ON.
Press the button for 5 seconds again
and the CHILD LOCK lamp will turn OFF.
you need it . This function is very helpful for parties and special occasions , where the
refrigerator is subjected to heavy load and you need instant cooling of the food. The super
cool system released when the temperature of refrigerator gets specified degrees.
the led to the ‘Cold' position.
not going to get disturbed for long time like one or two days you can save your electric
power by forcing the Energy saver function.
Pressing any other key (Except Child Lock) or opening the door will release the refrigerator
from Energy Saver mode.
9
Applicable For GL-432 DMX
