Operation
11
l
l
l
l
l
l
l
l
l
Cool air vent is placed on the refrigerator door to
provide cool air to door shelves.
If foreign substances enters the cool air vent while
cleaning, efficiency will be lowered. In addition, if
gasket is damaged, efficiency may be lowered due to
the escape of cool air. So care should be taken during
cleaning.
When the door is opened, the warmer air doesn’t influence
the cooling of chiller compartment. So you can keep food
fresher in it.
Defrosting takes place automatically in every 8 hours of
actual compressor running.
The defrost water flows down to the evaporating tray
which is located in the lower back side of the
refrigerator and is evaporated automatically.
By using a catalyst, deodorizing performance is
guaranteed.
Unpleasant odor of food in fresh food compartment is
deodorized with no harm to you and the food.
As the catalyst is located in cooling air outlet in fresh
food compartment, there is no need for any handling.
Do not prick the cooling air outlet with a sharp tip
because the deodorizer catalyst may be damaged.
When storing food with a strong odor, wrap it or store it
in a container with lid because odor may be passed to
other food.
Use bank ice only to store ice cubes.
Do not make ice in it, as it may break.
Ice Trays
Bank Ice
Instruction to
use bank ice
l to remove ice cubes,
hold the knob of the tray and turn gently in the clock
wise direction, ice cubes drop in the bank ice.
Cool air Vent
Ice beam
Door cooling
Chiller Compartment
Defrosting
Deodorizer
How to Use
Your refrigerator has Triple twist ice tray
l to make ice cubes,
fill the ice tray with water upto the water level mark
and insert in its position.
Ice making
Water
Level
