8
AUDIO SETTINGS
While listening to any source...
1 Press AUDIO to select
[AUD CTRL]
.
2 Turn the volume knob to make a selection (see the table below), then press
the knob.
Repeat step 2 until the desired item is selected or activated.
3 Press and hold to exit.
• To return to the previous hierarchy, press
.
Default:
XX
SW LEVEL –15 to +15 (0): Adjusts the subwoofer output level.
BASS LVL
–8 to +8 (0):
Adjusts the level to memorize for each source. (Before making
an adjustment, select the source you want to adjust.)
MID LVL
–8 to +8 (0):
TRE LVL
–8 to +8 (0):
EQ PRO
BASS ADJ BASS FRQ
60/ 80/ 100/ 200: Selects the center frequency.
BASS LVL
–8 to +8 (0): Adjusts the level.
BASS Q
1.00/ 1.25/ 1.50/ 2.00: Adjusts the quality factor.
BASS EXT
B-EX ON: Turns on the extended bass. ; B-EX OFF: Cancels.
MID ADJ MID FRQ
0.5K/ 1.0K/ 1.5K/ 2.5K: Selects the center frequency.
MID LVL
–8 to +8 (0): Adjusts the level.
MID Q
0.75/ 1.00/ 1.25: Adjusts the quality factor.
TRE ADJ TRE FRQ
10.0K/ 12.5K/ 15.0K/ 17.5K: Selects the center frequency.
TRE LVL
–8 to +8 (0): Adjusts the level.
EQ
NATURAL/ USER/ ROCK/ POPS/ EASY/ TOP40/ JAZZ/ POWERFUL: Selects
a preset equalizer suitable to the music genre. (Select [USER] to use the
customized bass, middle, and treble settings.)
B. BOOST
BB-L LV1/
BB-L
LV2/
BB-L
LV3: Selects your preferred bass boost level. ;
BB-L OFF: Cancels.
LOUDNESS LOUD LV1/ LOUD LV2: Selects your preferred low and high frequencies boost
to produce a well-balanced sound at a low volume level. ; OFF: Cancels.
BALANCE
L15 to R15 (0): Adjusts the left and right speaker output balance.
FADER R15 to F15 (0): Adjusts the rear and front speaker output balance.
SW SET
SW ON: Turns on the subwoofer output. ; SW OFF: Cancels.
DTIL SET
LPF SW
LPF THRU
: All signals are sent to the subwoofer. ; LPF 85HZ/ LPF 120HZ/
LPF 160HZ: Audio signals with frequencies lower than 85 Hz/ 120 Hz/ 160 Hz
are sent to the subwoofer.
SW PHASE PHAS REV (180°)/ PHAS NML (0°): Selects the phase of the subwoofer
output to be in line with the speaker output for optimum performance.
(Selectable only if a setting other than [LPF THRU] is selected for [LPF SW].)
SPRM SET SPRM ON: Creates realistic sound by interpolating the high-frequency
components that are lost in AAC/MP3/WMA audio compression. ;
SPRM OFF: Cancels. (Selectable only when playing back an AAC/MP3/WMA
disc or a USB device, except iPhone/iPod.)
V-OFFSET
(Default: 0)
–8 to +8 (for AUX) ; –8 to 0 (for other sources): Presets the volume
adjustment level of each source. (Before adjustment, select the source you
want to adjust.)
•
[SW LEVEL]
/
[SW SET]
/
[LPF SW]
/
[SW PHASE]
is selectable only if
[SWPRE]
is set to
[SWPRE SW]
. (➜
4
)
•
[SW LEVEL]
/
[LPF SW]
/
[SW PHASE]
is selectable only if
[SW SET]
is set to
[SW ON]
.
