7
EN
Troubleshooting
Q1: The power cannot be turned on.
A1: • The batteries may be depleted.
• The batteries may be inserted
incorrectly.
Check = and - before inserting
new batteries.
• Are the terminals of the batteries
soiled?
If so, clean them with a dry cloth.
Q2: Nothing happens when a button
is pressed.
A2: • The POWER switch may be set
to the [OFF/HOLD] position.
Slide the POWER switch to the
[ON] position.
Q3: No sound or quiet sound is heard
from the speaker while playing
back.
A3: The earphone plug may be
plugged into the recorder.
The volume may be set to the
minimum level.
Q4: Recording is not possible.
A4: By pressing the REC (s) button:
• Check if the display shows
[FULL].
Delete any unnecessary file
before recording any further.
A maximum of 200 files can be
recorded.
Q5: The playback speed is too fast
(slow).
A5: The recorder may be set to fast
(slow) playback.
Playback speed is set to
[1.0 PLA
y
].
Specifications
Recording medium:
Built-in flash memory (1 GB)
Input level:
—
70 dBv
Maximum headphone output:
3 mW (at load of 8 )
Speaker:
Built-in ø 28 mm round dynamic
speaker
MIC jack:
ø 3.5 mm mini-jack, impedance 2 kΩ
EAR jack:
ø 3.5 mm mini-jack, impedance 8 Ω
or more
“CE” mark indicates that
this product complies with
the European
requirements for safety, health,
environment and customer
protection.
This symbol [crossed-out
wheeled bin WEEE Annex
IV] indicates separate
collection of waste
electrical and electronic
equipment in the EU
countries. Please do not throw the
equipment into the domestic refuse.
Please use the return and collection
systems available in your country for
the disposal of this product.
Applicable Product: VN-750
This symbol [crossed-out
wheeled bin Directive
2006/66/EC Annex II]
indicates separate
collection of waste batteries in the
EU countries. Please do not throw the
batteries into the domestic refuse.
Please use the return and collection
systems available in your country for
the disposal of the waste batteries.
Maximum working output:
190 mW (8 Ω speaker)
Overall frequency response:
SP mode: 300 Hz to 4.7 kHz
LP mode: 300 Hz to 2.9 kHz
Guide to recording times:
SP mode: Approx. 100 h.
LP mode: Approx. 573 h.
Input power requirement:
Two AAA (LR03) batteries
Guide to battery life:
During recording mode
(Built-in microphone)
SP mode: Approx. 86 h.
LP mode: Approx. 57 h.
During playback mode
(Built-in speakers)
SP mode: Approx. 21 h.
LP mode: Approx. 21 h.
(Earphone)
SP mode: Approx. 53 h.
LP mode: Approx. 57 h.
External dimensions:
104 (L) mm x 37 (W) mm x 19.1 (T)
mm (without protrusions)
Weight:
66 g (including battery)
Operating temperature:
0°C - 42°C
• Available recording time may be
shorter if many short recordings are
made.
• Battery life is measured by Olympus.
It varies greatly according to the
type of batteries used and the
conditions of use.
• Your recorded contents are for your
personal use or pleasure only. It is
prohibited to record copyrighted
material without permission of the
copyright holders according to
copyright law.
• Specifications and design are
subject to change without notice
for improvement of performance.
Accessories (optional)
s Compact zoom microphone
(unidirectional): ME32
s Highly sensitive noise-cancellation
monaural microphone
(unidirectional): ME52W
s Tie clip microphone
(omni-directional): ME15
s Telephone pickup: TP7
s Connecting cord: KA333
