The expelled cooling air can be guided in the most favourable direction by the ducting flap 1 1 4 5 Dust extraction The dust produced while working can be detrimental to health combustible or explosive Suitable safety measures are necessary The dust bag 4 1 with the adopter 4 3 is at tached to the exhaust duct 4 2 by means of a bayonet catch by turning to the right The dust bag is removed for emptying by turning it to the left At the time of fixing ensure that the leaf spring stud touches the belt housing The dust extraction system will continue to func tion effectively as long as the bag is emptied in good time For working with the protection of the environ ment in mind it is advisable to use the Festool dust extraction system The connecting socket from the suction hose can be connected using the adapter 4 4 which is sup plied as standard 4 1 Working with the sanding frame in the case of type BS 75 E Set Set the machine with the knurled head screw 2 4 so that when it is placed on the workpiece surface the sanding belt does not engage Thesanding belt isengaged by turning the knurled head screw towards the plus symbol until the belt makes contact Continue turning the knurled screw to achieve the desired depth of stock removal 1 complete turn corresponds to a height adjustment of 0 4 mm When interrupting or on completing work the sander is raised from the working position 2 3 set to a position of rest 2 2 by means of an ec centric lever By swinging the eccentric lever back to working position the depth of stock removal set previously is again obtained 4 2 Taking the sanding frame off Press down the knurled head screw 2 4 until the shank 2 5 springs out of the spring catch and the machine can be withdrawn from the rear The sanderand sanding frame arealigned j for optimum accuracy at the factory by suitable adjustment of the guiding struts For this reason do not remove the guiding struts 4 6 Stationary use partly accessories Attach both feet 5 3 via the two threaded holes 4 5 Important the straight edges of the feet must face inwards Make sure that the machine is standing firmly use clamps to attach the feet to the base 4 7 Stationary use partly accessories Attach the longitudinalstop to the threaded hole 5 2 using screw 5 1 Unscrew the screw 6 3 to adjust the position of the longitudinal stop along the sanding belt To sand sloping surfaces unscrew the screw 6 2 and adjust the longitudinal stop The scale 6 1 indicates the angle setting 4 3 Assembling the sanding frame Make sure that the glide pins 2 6 2 8 fixed to the sanding frame engage front and back in the grooves of the guide struts 2 7 2 9 Slide the sander downwards along the grooves until the shank 2 5 engages 5 Maintenance and care When the graphite coating on the pad lining 3 3 is heavily worn this has to be replaced To do this the 3 cheese head screws 3 1 are loosened and the strip 3 2 removed Asanding support for rough work at high removal rates is available The belt sander requires practically no mainte nance The lubrication for the antifriction bearings and gears is designed to last for the service life of the machine It is advisable to clean the air intake and outlet ports and the dust suction and extraction channel occasionally with compressed air while the sander 4 4 Changing the sanding belt Pull the lever 3 5 forward the belt is now slack and can be removed When fitting a new belt take special care to ensure that the arrow on the inside of the belt points in the same direction as that on the sander 3 4 Tighten the belt again with the lever and align when running 12
