English - 29
Troubleshooting: Before Contacting Service Personnel
No sound or picture Check that the mains lead has been connected to a wall socket.
Check that you have pressed the button on your set.
Check the picture contrast and brightness settings.
Check the volume.
Normal picture but no sound Check the volume.
Check whether the
MUTE
M
button has been pressed on the remote control.
Check the
Speaker Select settings.
Screen is black and power
indicator light blinks steadily
On your computer check; Power, Signal Cable.
The TV is using its power management system.
Move the computer’s mouse or press any key on the keyboard.
No picture or black and white
Adjust the colour settings.
Check that the broadcast system selected is correct.
Sound and picture interference Try to identify the electrical appliance that is affecting the set and move it further away.
Plug your set into a different mains socket.
Blurred or snowy picture,
distorted sound
Check the direction, location and connections of your aerial.
This interference is often due to the use of an indoor aerial.
Remote control malfunctions Replace the remote control batteries.
Clean the upper edge of the remote control (transmission window).
Check the battery terminals.
‘Check signal cable.’ message is
displayed

Check that the PC or video sources are turned on.
On PC mode, ‘Not Supported
Mode.’ message is displayed

Compare these values with the data in the Display Modes.
The damaged picture appears in
the corner of the screen
If Screen Fit is selected in some external devices, the damaged picture may appear in
the corner of the screen. This symptom is caused by external devices, not TV.
The ‘Resets all settings to
the default values.’ message
appears.
This appears when you press and hold the EXIT button for a while. The product settings
are reset to the factory defaults.
You may see small particles if
you look closely at the edge of
the bezel surrounding the TV
screen.
This is part of the product’s design and is not a defect.

However, there may be few bright or dark pixels on the screen. These pixels will have no impact on the performance of the
product.

Model Name LE32B530P, LE32B541P LE37B530P LE40B530P, LE40B541P LE46B530P
Screen Size
(Diagonal) 32 inches 37 inches 40 inches 46 inches
PC Resolution
(Optimum) 1920 x 1080 @ 60 Hz 1920 x 1080 @ 60 Hz 1920 x 1080 @ 60 Hz 1920 x 1080 @ 60 Hz
Sound
(Output) 10W x 2 10W x 2 10W x 2 10W x 2
Dimensions (WxDxH)
Body
With stand
801 X 77 X 518 mm
801 X 220 X 562 mm
918 X 77 X 597 mm
918 X 300 X 650 mm
998 X 78 X 621 mm
998 X 260 X 686 mm
1127 X 78 X 712 mm
1127 X 260 X 766 mm
Weight
With Stand 12 kg 15 kg 18 kg 24 kg
Environmental
Considerations
Operating Temperature
Operating Humidity
Storage Temperature
Storage Humidity
10°C to 40°C (50°F to 104°F)
10% to 80%, non-condensing
-20°C to 45°C (-4°F to 113°F)
5% to 95%, non-condensing
Stand Swivel
Left / Right 

This device is a Class B digital apparatus.
For the power supply and Power Consumption, refer to the label attached to the product.
¦
N
¦
N
N
N
BN68-01893F-Eng.indd 29 2009-02-24 ฀฀ 2:57:24
