Samsung LE-37 B530P7 [5/61] Viewing the connection panel

English - 3

Viewing the Connection Panel

The product colour and shape may vary depending on the model.

Whenever you connect an external device to your TV, make sure that power on the unit is turned off.

When connecting an external device, match the colour of the connection terminal to the cable.

1

DIGITAL AUDIO OUT (OPTICAL)

Connects to a Digital Audio component such as a Home theatre receiver.

When the HDMI IN jacks are connected, the

Connects to an antenna or cable TV system.

4

PC/DVI(HDMI 1)[AUDIO]

Connect to the audio output jack on your PC.

DVI audio outputs for external devices.

5

AUDIO OUT [R-AUDIO-L]

Connect RCA audio cables to AUDIO OUT [R-AUDIO-L] on the rear of your set and the other ends to corresponding



6

KENSINGTON LOCK (depending on the model)



use a locking device, contact the dealer where you purchased the TV.

HDMI) for video connection and the PC/DVI(HDMI 1)[AUDIO] jacks for audio.

You can also use the ports to connect to a PC.

What is HDMI?



digital audio.

The HDMI / DVI terminal supports DVI connection to an extended device with the appropriate cable (not supplied).

The difference between HDMI and DVI is that the HDMI device is smaller in size, has the HDCP (High Bandwidth Digital

Copy Protection) coding feature installed, and supports multi - channel digital audio.
