EN
What is included in the box
Supply of this TV includes following parts:
• 1x TV • 1x RF cable
• 1x Remote control • 1x TV stand installation packet
• 2x AAA batteries • 1x User guide
• 1x Mini Component adapter
cable**
• 1x Mini Composite adapter
cable
• 1x SCART adapter cable*
* - supplied only for models without SCART connector
** - Aviable only for models with Mini Component
Attaching the Stand
Please follow the instructions on last page of this user manual.
Getting started - initial set up
1. Insert the batteries supplied into the Remote control.
2. Using the RF cable supplied, connect the TV to the TV Aerial wall
socket.
3. For connecting to the Internet with a wired connection connect a
Cat 5/Ethernet cable (not included) from the TV to your broadband
modem/router.
4. Connect the power cable to the Electrical outlet.
5. Usually the TV supplied with a pre-paired remote control unit (RCU).
If the TV does not respond to remote control commands, follow the
instructions below.
Pairing the remote control unit (RCU):
a) If the TV turns on automatically and the window "First Time
Installation" found appeared on the screen, press and hold for a few
seconds green and yellow buttons on the RCU. The power indicator
will blink 5 times, that would con rm the pairing of TV and RCU
completed.
b) If the TV does not automatically turn on, you need to power it on by
using of standby key allocated on the TV (but not on the RCU). After TV
started up press once again a standby button, then there menu "Pair
your remote" will appear. Scroll the cursor down using the buttons
CH+/CH, to select "Pair your remote", and con rm it by pressing
standby button one more time. Simultaneously press and hold for
a few seconds green and yellow buttons on the RCU. The power
indicator will blink 5 times, thus con rming the pairing of the TV and
the remote control completed.
Now proceed next steps to con guring the TV.
6. After turning on the TV you will see the menu "First Time Installation".
If the menu does not appear, You can recall it by pressing the remote
control buttons "Menu", then 8-8-8-8, so this menu window would be
re-opened.
If you wish to make changes to any of the default settings, use the
scroll ▲/▼/◄/► buttons. To exit this menu at anytime, press [EXIT]
button.
7. Please set desired settings in FIRST TIME INSTALLATION screen.
DVB Antenna - You can choose between Terrestrial (DVB-T/T2), Cable
(DVB-C) or Satellite (DVB-S/S2)*.
Language - Set the TV Menu language.
Country - Set the desired country.
Tunning Mode - Choose if you want to tune only Digital (DTV)
Analogue (ATV) or both Digital and Analogue (DTV + ATV)
Operator - Select Cable provider. If your cable operator is not listed
select Others. (Avaliable only if DVB Antenna is set to CABLE)
Environment - Select the location of TV.
For home use, please select Home Mode.
For shop demonstration mode, set Store Mode.
Sorting by LCN - Set LCN to ON if you want to arrange channels by
provider preferences (only applies to DVB-T and DVB-C channels).
8. Press [Auto Tuning] button to start the tuning process.
9. Optional channel presets DVB-C:
Keep all default settings as recommended.
If DVB-C channels are not found, contact your network provider for the
valid "Network ID". Then perform anew search. Press the [MENU], select
"Network ID" and enter the network ID.
10. Optional channel presets DVB-S2*: Select "Satellite" in the "DVB
Antenna" in the menu for the optional channel presets. Here you can
choose between the various satellites. Since selection completed, then
the channel list of the exact satellite will be available to be imported
into your TV system.
Con rm with [OK] button on the remote control, to start scanning.
TIP: If you are missing channels, the reason for this is likely to be signal
strength, you should consider connecting signal booster and re-tuning the TV.
* - Available only for TVs with DVB-S tuner
Remote control
Radio controlled remote control - No more aiming in the TV direction!
Refer to remote control picture on the second page of this user
manual.
1.
STANDBY – Switch on TV when in standby or vice versa.
2.
MUTE – Mute the sound or vice versa.
3. 0 – 9 – to select aTV channel directly.
4. TV GUIDE – Opens the 7 Day TV Guide (Digital mode).
5.
– To return to the previous channel viewed.
6. PICTURE – Scrolls through picture mode options.
7. VOL ▲/▼ – To increase / decrease the sound level.
8. CH ▲/▼ – To increase or decrease the channel being watched.
9. SOUND – Scrolls through sound mode options.
10. SOURCE – To display the input/source menu.
11. MENU – To display OSD menu.
12. EXIT – To exit all menus.
13. (▲/▼/◄/►/ OK) – Allows you to navigate the on-screen menus and
adjust the system settings to your preference.
14. INFO – Press once for now/next channel information. Press twice for
programme information about current programme.
15. FAV – To display favourites menu.
16. SLEEP – Press repeatedly to cycle through the sleep options.
17. TEXT – Teletext mode - To enter Teletext
18. SUBTITLE – To switch the dialogue at the bottom of the screen (on/
o ).
19. ASPECT – To switch the screen between the di erent picture formats.
20. TV – Switch to digital TV source.
21. MEDIA – Switch to USB source.
22. RADIO – Switch to Digital radio stations.
23. Rec
1
– PVR Record
24.
– To restart the current chapter
25.
– To advance forward to the next chapter
26.
/
– To stop the playback / To EJECT the disc press/hold the button
for 4 seconds.
27. Rec List
1
– Opens the list of recordings.
28.
– To play in fast rewind mode.
29.
– To play in fast forward mode.
30.
– To play/pause
31. COLOUR BUTTONS
– Additional teletext and OSD functions
1
- available only with PVR function
