GB
Translation of original user instructions
26
Petrol lawnmower
Starting the motor
Caution - risk of poisoning!
Never leave a motor running in an enclosed
space.
Caution - Risk of injury!
Do not tilt the lawnmower while starting.
▪ Start the motor only when the blade is mounted
(thebladeactsasaywheelmass)
▪ If starting the motor when hot do NOT use the
choke or primer button
▪ Do not change the motor controller settings
Do not start the equipment if the outlet shaft is not
covered by one of the following parts:
Grass catcher
Deectorplate
Mulch kit
Be particularly careful when operating the starter
switch - follow the manufacturer's instructions
Keep your feet at a safe distance from the cutting
gear
Start the lawnmower where the grass is shorter
hold it ( 16) - the brake handle does not lock.
3. Pull out the starter cord sharply, then allow it to
slowly rewind ( 17).
4. When the motor has warmed up (about 15–20
seconds), set the throttle lever to a position
between min and max.
with remote throttle control, with primer ( 16)
1. Set the throttle lever to position max ( 12/1).
2. Press the primer button 3 times at intervals of about
2 seconds ( 15). If the temperature is below
10 °C, press the primer button 5 times.
3. Pull in the safety brake handle on the handlebar and
hold it ( 16) - the brake handle does not lock.
4. Pull out the starter cord sharply, then allow it to
slowly rewind ( 17).
5. As soon as the motor starts running, set the throttle
lever for the desired motor rpm, at a position
between min and max.
Starting electrically (optional)
Electrostart with primer ( 13)
1. Set the throttle lever to the "S TA R T " position
( 13/1).
2. Press the primer button 3 times at intervals of about
2 seconds ( 15). If the temperature is below
10 °C, press the primer button 5 times.
3. Pull in the safety brake handle on the handlebar and
hold it ( 16) – the brake handle does not lock.
4. Turn the ignition key fully to the right in the ignition
lock ( 18).
5. As soon as the motor starts running, release the
ignition key (it returns automatically to position "0").
6. According to the desired motor speed, set the
throttle lever to a position between min and
max.
Starting manually
with remote throttle control, with choke
1. Set the throttle lever to position max
( 11/1).
2. Pull in the safety brake handle on the handlebar and
hold it ( 16) – the brake handle does not lock.
3. Pull out the starter cord sharply, then allow it to
slowly rewind ( 17).
4. When the motor has warmed up (about 15–20
seconds), set the throttle lever to a position
between min and max.
with remote throttle control, without primer/choke
1. Set the throttle lever to position max ( 12/1).
2. Pull in the safety brake handle on the handlebar and
