Subaru RG3200iS 60Hz Silent [19/42] Section 6 electric device group

REF PART NO DESCRIPTION QTY REMARKS FROM - TO FIG

RG3200iS - 19 - 07-04

SECTION 6 ELECTRIC DEVICE GROUP

120 277-70502-00 STARTING MOTOR 1 720

-1 277-70550-08 YOKE 1

720

-6 277-70551-08 ARMATURE 1

720

-7 277-70520-08 CLUTCH 1 720

-8 277-70561-08 NUT 1 720

-9 277-70501-08 GEAR HOUSING 1

720

-11 277-70502-08 FRAME 1

720

-15 277-70573-08 CONTACTOR 1 720

-16 227-70562-08 RING, snap 1

720

-17 277-70570-08 THROUGH BOLT 2 720

-19 254-70576-08 NUT 2

720

-20 227-70573-08 WASHER 1 720

-32 277-70574-08 CREW 2 720

-33 277-70560-08 SPRING 1

720

-43 227-70574-08 COLLAR 1

720

-44 227-70572-08 O RING 2 720

-46 277-70571-08 O RING 2 720

-49 277-70572-08 WIRE 5 1

720

-73 227-70577-08 BOLT and WASHER 1 720

128 980-40081-10 STR PIN 1

720

130 011-00604-80 FLANGE BOLT 1 720

131 011-00604-70 FLANGE BOLT 1

720
