Subaru RG3200iS 60Hz Silent [25/42] Section 7 engine group

REF PART NO DESCRIPTION QTY REMARKS FROM - TO FIG

RG3200iS - 25 - 07-04

SECTION 7 ENGINE GROUP

610 278-62330-00 CARBURETOR 1 2160

-1 277-62536-08 THROTTLE VALVE 1

2160

-2 284-62455-08 SCREW and WASHER 2

2160

-3 284-62525-08 CHOKE VALVE 1

-11 277-62532-08 THROTTLE SHAFT 1 2160

-12 284-62355-08 BOLT and WASHER 1

2160

-14 279-62500-08 NEEDLE 1 2160

-15 284-62515-08 PIN 1

2160

-16 284-62550-08 FLOAT BODY 1 2160

-17 251-62350-08 PACKING 1

2160

-18 284-62540-08 CHAMBER PACKING 1 2160

-28 251-62466-08 BOLT 1

2160

-32 251-62559-08 SEAL 1 2160

-40 277-62581-08 ADJUST SCREW 1

2160

-41 251-62449-08 SPRING, choke 1 2160

-107 284-62561-08 COLLAR 2

2160

-109 284-62315-08 THROTTLE SPRING 1 2160

-151 284-62451-08 O RING 1 2160

2160

-402 284-62576-08 BRACKET, motor 1 2160

-404 277-62595-08 COVER, motor 1 2160

-406 284-62458-08 SCREW 2

2160

-408 284-62457-08 SCREW 2 2160

-410 284-62555-08 JOINT LEVER 1 2160

-412 284-62446-08 SPRING, choke 1

2160

-420 284-62575-08 BRACKET 1
