Subaru RG4300iS 50Hz Silent [11/44] Section 3 intake exhaust group

REF PART NO DESCRIPTION QTY REMARKS FROM - TO FIG

RG4300iS - 10 - 09-04

RG4300iS - 11 - 09-04

SECTION 3 INTAKE, EXHAUST GROUP

10 279-31602-11 CAMSHAFT 1 300

25 277-35101-03 PIN, camshaft 1 300

27 024-00600-10 O RING 1 300

34 277-38601-03 PIN, spring 1 300

35 279-36401-03 RELEASE LEVER 1 300

37 277-36501-03 CLIP 1 300

38 279-38701-13 RETURN SPRING 1 300

60 279-33601-03 VALVE SPRING 2 300

70 269-33701-03 SPRING RETAINER 2 300

80 279-33401-13 INTAKE VALVE 1 300

90 279-33501-13 EXHAUST VALVE 1 300

95 132-10KA0-31 COLLET VALVE 4 300

150 279-35601-11 TIMING CHAIN 1 300

160 277-36911-03 TENTIONER 1 300

163 277-37101-03 SPRING, tentioner 1 300

166 277-36902-03 PIN, tentioner 1 300

170 277-36913-13 CHAIN GUIDE 1 300

200 277-35002-01 PIN, rocker 1 300

202 003-13050-00 CLIP 1 300

220 277-36201-00 ROCKER ARM, intake 1 300

225 277-36202-00 ROCKER ARM, exhaust 1 300

230 014-90500-20 ADJUST SCREW 1 300

231 014-90500-20 ADJUST SCREW 1 300

240 017-00500-30 NUT 1 300

241 017-00500-30 NUT 1 300

290 011-00600-20 FLANGE BOLT 1 300
