Subaru RG4300iS 50Hz Silent [31/44] Section 23 base frame group

REF PART NO DESCRIPTION QTY REMARKS FROM - TO FIG

RG4300iS - 30 - 09-04

RG4300iS - 31 - 09-04

SECTION 23 BASE, FRAME GROUP

10 34J-30001-01 FRAME CP 1 2300

40 33B-35602-01 BATTERY BASE 1 2300

43 011-00600-80 FLANGE BOLT 2 2300

44 014-00601-21 SCREW 1 2300

50 34J-53101-01 BASE PLATE, lower 1 2300

80 34G-59005-03 SPONGE, BASE 1 2300

110 34J-53002-01 BASE PLATE, UPPER 1 2300

120 001-14081-60 BOLT and WASHER 4 2300

130 34G-59006-03 SPONGE, BASE 1 2300

180 393-30603-01 WHEEL 1 2300

320 32B-30214-01 MOUNT, LEFT 1 2300

321 32B-30213-01 MOUNT, RIGHT 1 2300

322 32B-30203-01 MOUNT, RIGHT 1 2300

323 32B-30204-01 MOUNT, LEFT 1 2300

330 002-38080-01 FLANGE NUT 8 2300

350 34G-55201-01 WHEEL SHAFT 2 2300

370 34G-56002-10 BRAKE 2 AY 1 2300

376 34G-56102-13 SPRING, BRAKE 1 2300

380 001-14081-60 BOLT and WASHER 1 2300

440 33B-48091-01 EARTH WIRE 1 2300

441 34B-48091-01 EARTH WIRE 1 2300

625 34G-55211-21 DRAIN GUIDE 1 2300

627 011-00600-20 FLANGE BOLT 1 2300

782 011-00600-20 FLANGE BOLT 2 2300

786 003-11120-00 WASHER 3 2300

790 005-10302-50 COTTER PIN 4 2300

815 33B-58001-01 BATTERY BAND 1 2300

832 33B-48072-11 BATTERY WIRE 1 2300

837 33D-35701-03 BATTERY COVER 1 2300
