DAIKIN OPTIONAL PARTS BKS028A4
Two-dimensional bar code
is a code for manufacturing.
3P290325-1A M11B010A
Accessories
Limitations on Place of Installation
1. Assembling the installation frame.
1) Fix the floor anchor, side support (R), side support (L), and reinforce plate at the 6 locations using the
parts shown below.
( Bolt (M6 × 16L), Washer (M6), Spring washer (M6) , Nut (M6))
2. Fix the installation frame.
2-1) Fix the installation frame at 2 locations on the
floor surface using the M10 foundation bolts.
(field supply: M10 foundation bolt)
2-2) Fix the installation frame at 4 locations on the
wall using screws. (field supply: M4 × 25L)
Installation Procedure
Floor anchor
A
Reinforce plate
D
Cover
G
Washer (M6)
K
Side support (R)
B
Support plate
E
Thermal insulation
H
Spring washer (M6)
L
Side support (L)
C
Support cover
F
Bolt (M6 × 16L)
J
Nut (M6)
M
Screw (M4 × 8L)
N
21112
1216
1166
25
45
142 (gas pipe)
157 (liquid pipe)
60
720
* Maximum height
(for air conditioner installation)
150
403
233
* Maximum depth
(for air conditioner installation)
223
unit: mm
950
* Maximum width
(for air conditioner installation)
105
105
537.5
244537.5
43
* M10 foundation bolt
* Fixing holes
on the wall
A
J K L M
B C D
CAUTION
• Be sure to fix the installation frame
on the floor surface firmly using
M10 foundation bolts.
• Fix the installation frame to a
sufficiently strong wall that can
bear the heavy load of the unit.
Floor anchor
A
Side support (R)
B
Side support (L)
C
M
M
L
K
K
K
L
K
J
J
Reinforce plate
D
Cross-section diagram
* Be careful of the installation direction.
Face the cut surface inside.
Floor anchor
A
Reinforce plate
D
Washer (M6)
K
Washer (M6)
K
Spring washer (M6)
L
Bolt (M6 × 16L)
J
Nut (M6)
M
Screws (field supply: M4 × 25L)
(4 locations)
M10 foundation bolts (field supply)
(2 locations)
M10 nuts (field supply)
(2 locations)
Right pipingLeft piping
Right back pipingLeft back piping
Right bottom pipingLeft bottom piping
406 (liquid pipe)
369 (gas pipe)
01_EN_3P290325-1A.fm Page 1 Monday, August 22, 2011 5:32 PM
Содержание
- Accessories 1
- Assembling the installation frame 1
- Caution 1
- Daikin optional parts bks028a4 1
- Fix the installation frame 1
- Installation procedure 1
- Limitations on place of installation 1
- P290325 1a m11b010a 1
- 1 hook the air conditioner on the mounting plate supplied with the air conditioner and fix it at 2 locations on the installation frame using screws screw m4 8l 2
- 1 remove the pipe port cover on the bottom right of the air conditioner 2
- 2 after connecting the field piping drain hose and inter unit wiring fix the cover at 3 locations on the installation frame using screws screw m4 8l 2
- 2 set the thermal insulation and cover the field piping drain hose and inter unit wiring with it note the thermal insulation is used only when it is routed under the support cover 2
- 3 fix the support cover at 8 locations on the installation frame using screws screw m4 8l 2
- 4 fix the support plate 2 pcs at 6 locations on the installation frame using screws screw m4 8l 2
- 5 fix the mounting plate supplied with the air conditioner at 6 locations on the installation frame using screws screw m4 8l 2
- Cross section diagram 2
- Diagram of finished unit 2
- In accordance with the direction of the piping remove the pipe port cover of the cover on either the left or right 2
- Installing the air conditioner and performing finishing 2
- Preparing for the air conditioner installation 2
