- 1 safety precautions 4
- Contents 4
- First of all 4
- Installation manual 4
- 2 special notice of product 5
- 1 standard supplied accessories 6
- 2 example of system configuration 6
- 3 disposal requirements 6
- Before installation 6
- 3 indoor unit constraints refrigeration and freezer 7
- 4 indoor unit constraints air conditioning 7
- No limit to wall height 7
- Selection of location 7
- When installed as a single unit 7
- When installed in serial 7
- Handling the unit 8
- Base form 9
- Base width and base bolt positions 9
- Depth of product 9
- Foundation bolt point 4 15 22 9
- Inner dimension 9
- Of the base 9
- Or more 9
- Outer dimension 9
- Placing the unit 9
- Plastic washers 9
- Refrigerant piping 9
- To piping work contractors 9
- Unit mm 9
- 1 selection of piping material and size 10
- 2 selection of refrigerant branching 11
- 3 protection against contamination when installing pipes 11
- 4 pipe connection 11
- 5 drier installation 11
- 6 connecting the refrigerant piping 11
- Gas side shutoff valve provided with service port 11
- Handy valve 11
- Liquid side shutoff valve provided with service port 11
- Location to be brazed 11
- Maintenance shutoff valve 11
- Nitrogen 11
- Refrigerant pipe 11
- Regulator 11
- Taping 11
- Concave section 4 places 12
- Front connection 12
- Knock hole 12
- Left side connection 12
- Right side connection 12
- Air conditioner 13
- Brazing 13
- Gas side shutoff valve 13
- Hexagon hole 13
- Not apply a screw lock agent 13
- Screw thread apply a screw lock agent 13
- Sealing part 13
- Sealing part not apply a screw lock agent 13
- Service port 13
- Shaft sealing part 13
- Shutoff valve part of mounting the valve cover 13
- Valve cover 13
- A arrow view 14
- Air conditioner 14
- Branch piping 14
- Branch piping make the piping slant downward 14
- Brazing brazing 14
- Gas side shutoff valve 14
- Header 14
- Horizontal surface 30 or less 14
- Indoor unit side 14
- Knock hole 14
- Main piping make the piping slant downward 14
- Make the piping slant downward 14
- Outdoor unit side 14
- T joint 14
- All field wiring and components must be installed by a licensed 15
- Attach the power wire securely introducing power with a missing 15
- Attached clamp without applying external pressure on the terminal parts terminal for power wiring terminal for transmission wiring and earth terminal 15
- Be sure to install an earth leakage breaker the product incorpo 15
- Be sure to install an earth leakage circuit breaker 15
- Be sure to use a dedicated power circuit never use a power supply 15
- Calculated example the subcooling ratio with evaporative temperature at 10 c and condensing temperature at 45 c is equal to 19k liquid 15
- Caution 15
- Charge to eliminate the impact on other devices by reducing noise generated from the inverter device and to prevent leaked current from being charged in the outer hull of the product 15
- Completed or otherwise the compressor will malfunction 15
- Connect the wire securely using designated wire and fix it with 15
- Do not connect the ground wire to gas pipes sewage pipes light 15
- Do not operate the conveni pack until refrigerant piping work is 15
- Do not operate until refrigerant piping work is completed 15
- Do not remove any electrical components such as thermistors or 15
- Earth leakage circuit breaker which are especially for protecting 15
- Electrical wiring must be done in accordance with the wiring dia 15
- Electrician and must comply with relevant local and national regu lations 15
- Expansion valve selection 15
- Field wiring 15
- Grams and the description herein 15
- Ground faults should be used in conjunction with main switch or fuse for use with wiring 15
- If operated before complete the piping work the compressor may be broken down 15
- Install a switch that allows you to switch all poles from the main 15
- Is larger than this the unit s lifespan will be reduced if the ratio exceeds 4 the unit will shut down and an malfunction code will be displayed on the indoor remote controller 15
- Make sure the electrical unbalance ratio is no greater than 2 if it 15
- N phase or with a mistaken n phase will break the unit 15
- Never connect the power supply in reversed phase 15
- Never install a phase advancing capacitor as this unit is equipped 15
- Never remove thermistor sensor or etc when connecting power 15
- Ning rods or telephone ground wires gas pipes can explode or catch fire if there is a gas leak sewage pipes no grounding effect is possible if hard plastic pip ing is used telephone ground wires and lightning rods dangerous when struck by lightning due to abnormal rise in electrical potential in the grounding 15
- Only proceed with wiring work after blocking off all power always ground wires in accordance with relevant local and national 15
- Power supply 15
- Rates inverter equipment in order to prevent the malfunctioning of the earth leakage breaker make sure that the earth leakage breaker withstands harmonic interference 15
- Refrigerant temperature at 26 c 15
- Regulations 15
- Sensors when connecting power supply wires or transmission wires the compressor may malfunction if the conveni pack is operated with such electrical components removed 15
- Shared by another appliance 15
- The liquid temperature in the booster unit is further decreased the liquid temperature of the refrigeration showcase inlet is approximately 10 degrees of the target evaporating temperature of the outdoor unit 15
- The unit can not operate normally in reversed phase if you connect in reversed phase replace two of the three phases 15
- This machine includes an inverter device connect earth and leave 15
- This model has a larger degree of subcooling subcooling ratio condensing temperature liquid refrigerant temperature at outdoor unit outlet for the liquid refrigerant of a refrigerator than that of refrigerators without a subcooling mechanism as it cools the liquid refrigerant with a plate type heat exchanger 15
- This product have reversed phase protection detector that only 15
- This unit uses an inverter so install the earth leakage circuit breaker that be capable of handling high harmonics in order to pre vent malfunctioning of the earth leakage circuit breaker itself 15
- To electric engineering contractors 15
- When selecting an expansion valve for the load select one based on the subcooling ratio for the liquid refrigerant in the following table 15
- Wiring and transmission wiring if operated with thermistor sensor or etc removed the compres sor may be broken down 15
- With an inverter installing a phase advancing capacitor will not only deteriorate power factor improvement effect but also may cause capacitor abnormal heating accident due to high frequency waves 15
- Works when the power is turned on if there exists black out or the power goes on and off which the product is operating attach a reversed phase protection circuit running the product in reversed phase may break the compressor and other parts 15
- 1 example of wiring entire system 16
- 2 to open the electrical component box of the outdoor unit 16
- Capacity for operation output 0 a or less at ac 220 to 240v 16
- Electromagnetic contactor defrost heater defrost lamp 16
- Note 1 for remote switch use non voltage contact for microcurrent not more than 1ma 12vdc note 2 total capacity for warning alarm 0 a or less at ac 220 to 240v 16
- Thermostat for inner temperature adjustment defrost completion thermostat solenoid valve 16
- Timer for refrigeration timer for freezer 16
- 3 procedure for incoming wiring 17
- 4 procedure for power supply wiring 17
- Conduit 17
- Electric wiring label rear side of control box lid 17
- High voltage wiring 17
- Knockout hole for low voltage wiring 17
- Low voltage wiring 17
- Piping outlet 17
- Resin hook 17
- Terminal block 17
- Through hole cover cut the shaded area 17
- Wire narrow 17
- Wire thick 17
- Crimp style terminal 18
- Mount insulation sleeves fix the wiring with a clamp 18
- Power wire 18
- Secure remote operating switch wiring to the resin block using a clamp field supply 18
- 1 air tight test vacuum drying 19
- 5 procedure for wiring inside units 19
- Crimp style terminal 19
- Cup washer 19
- Cut out section 19
- Inspection and pipe insulation 19
- 2 thermal insulation work 20
- 3 checking of device and installation conditions 20
- Caulking etc 20
- Checking of device and installation conditions 20
- Connection procedure for gauge manifold and vacuum pump 20
- Field pipings note 20
- Gas side piping 20
- Gas side shutoff valve 20
- Indoor outdoor interunit piping insulation material 20
- Liquid side piping block 20
- Liquid side shutoff valve 20
- Meter vacuum pump 20
- Open a knock hole at 20
- Outdoor unit 20
- Piping lead out hole lid 20
- Position of instruction label 20
- Pressure reducing valve 20
- Shutoff valve service port 20
- Checks after work completion 21
- Refrigerant replenishment 21
- Stand the cylinder upright and fill the refrigerant there is a siphon tube inside which makes it possible to replenish the refrigerant in the state of liquid without setting the cylinder upside down 22
- Stand the cylinder upside down and fill the refrigerant pay attention so that the cylinder will not topple down 22
- Test run 22
- A1p tp1 tp2 23
- Inspection door right 23
- Maintenance and service 23
- Upper right portion of the electric accessory box 23
- A few bubbles flow 24
- Blower coil 24
- Booster unit 24
- Bubbles come out at all times 24
- Frozen showcase 24
- Full of liquid 24
- Indoor unit 24
- Outdoor unit 24
- Refrigeration showcase 24
- Sealed state shortage of refrigerant 24
Похожие устройства
- Daikin RDXYQ-T Руководство по монтажу
- Daikin REMQ-T Руководство по эксплуатации
- Daikin REYQ-T Руководство по эксплуатации
- Daikin RKXYQ-T Руководство по монтажу
- Daikin RQCEQ-P3 Руководство по установке
- Daikin RQEQ-P3 Руководство по установке
- Daikin RQYQ-P Руководство по установке
- Daikin RTSQ-PA Руководство по установке
- Daikin RTSYQ-PA Руководство по установке
- Daikin RWEYQ-T8 Инструкция по монтажу
- Daikin RX-GV.pdf Руководство по монтажу
- Daikin RX-GVB.pdf Руководство по монтажу
- Daikin RX-K.pdf Инструкция по монтажу
- Daikin RXG-L.pdf Инструкция по монтажу
- Daikin RXJ-M.pdf Дополнительная инструкция для оборудования
- Daikin RXM-L.pdf Дополнительная инструкция для оборудования
- Daikin RXM-M.pdf Дополнительная инструкция для оборудования
- Daikin RXN-L.pdf Инструкция по монтажу
- Daikin RXR-E.pdf Руководство по эксплуатации
- Daikin RXS-F8.pdf Руководство по монтажу
