Using external antennas
To improve FM reception
Use a PAL connector (not supplied) to connect an external FM
antenna.
Plugging in
CAUTION
Do not use any power cord other than the one supplied
with this unit.
Do not use the supplied power cord for any purpose
other than that described below.
Before making or changing the connections, switch off the
power and disconnect the power cord from the AC outlet.
After you’ve finished making all connections, plug the unit
into an AC outlet.
ANTENNA
FM
UNBAL
75 Ω
One-touch PAL
connector
75 :coaxial
cable
AC IN
SPEAKER
R
To AC outlet
This unit’s rear panel
Power cord
