HYUNDAI ELECTRONICS H-AP3-12H-UI005 [11/52] Important

11.

Electric air conditioner

portable type

IMPORTANT!

At high humidity additional condensate removal will be required (“E4”

symbol will be shown on the display). In this case a condensate collec-

tion tank at the device’s base is used.

In this case follow the instructions given below.

When the condensate collection tank is lled up, water needs to be

drained, otherwise the unit will not operate. Condensate should be

drained by opening the lower plug at the device’s base (Fig. 8).

But air conditioners are also designed to remove condensate continu-

ously without a need for a regular moisture removal from the device.

To do so it is necessary to use the drainage hose and perform the

following procedure:

1. Prepare the drainage hose for condensate removal;

2. Remove the plug from the back side of the device;

3. Insert the drainage hose into the condensate drainage hole;

4. Take the hose out to the drainage system to remove condensate;

A hole designed for continuous condensate removal in the center of

the device can be used for continuous condensate removal under

conditions of increased humidity inside a room.

To do so it is also necessary to perform the abovementioned proce-

dure.

Do not position the unit nearby objects that block air ow, for example, furniture or curtains since

it has a great impact on operation of the unit.

Keep the unit away from direct sunlight: it may cause overheating and shutdown of the unit.

ELECTRIC POWER SUPPLY

Make sure characteristics of the mains correspond to characteristics of the unit.

Insert the plug in the socket securely to avoid overheating and risk of re.

Do not pull the power cord with excessive force: it may damage it.

Fig. 8
