- 5
Order no. 6.414-805
Filter for pure blower air.
HEPA filter: Change once a year.
Illustration
Open cover.
Unlock the HEPA filter and remove.
Illustration
Insert the new HEPA filter and click it into
place.
Close the lid.
The ComfoGlide nozzle must be cleaned reg-
ularly!
Remove the nozzle from the suction pipe.
Illustration
Clean the back steering roller:
The easiest way to do this, is to remove
the roller. Unscrew the axle and pull out.
Dust fluff, hair etc. can now be removed
easily. Fit the steering roller back into
place.
Illustration
Handle and suction tube can be discon-
nected in order to clean or if clogged.
Push the 2 interlocks and pull apart.
Connect handle and suction tube and in-
sert.
Note: The battery should not be empty if you
want to ensure cable-free transmission.
Please replace the battery if you see no reac-
tion or just inadequate reaction when you
press the keys.
Slide and remove the battery compart-
ment cover.
Remove old batteries and dispose them
off properly.
Insert new batteries; pay attention to cor-
rect polarity.
Replace the battery compartment cover
and close it.
The terms of the guarantee applicable in each
country have been published by our respec-
tive national distributors. We will repair possi-
ble faults on your unit free of charge within the
warranty period, insofar as the faults are
caused by material defects or defective work-
manship. Guarantee claims should be ad-
dressed to your dealer or the nearest
authorized customer service centre, and sup-
ported by documentary evidence of purchase.
(See address on the reverse)
Our KÄRCHER branch will be pleased to help
you further in the case of questions or faults.
See address on the reverse.
At the end of the operating instructions you
will find a selected list of spare parts that are
often required.
You can procure the spare parts and the at-
tachments from your dealer or your KÄRCH-
ER branch office.
(See address on the reverse)
Subject to technical modifications!
Change the HEPA-filter
Cleaning of the ComfoGlide nozzle
Cleaning the accessories
Changing the battery
General notes
Warranty
Customer Service
Ordering spare parts and special at-
tachments
Technical specifications
Voltage
220 - 240
V
Current type
50/60
Hz
Mains fuse (slow-blow)
13
A
Protective class
II
Output P
nom
1800
W
Output P
max
2000
W
Weight (without accesso-
ries)
7,0
kg
Action radius
10
m
Dimensions
ø 380 x
380
mm
Nominal width, accesso-
ries
35
mm
Sound pressure level L
pA
66
dB(A)
