4-2 Samsung Electronics

4-2 Checking the Oil

4-2-1 Oil quality

4-2-2 Changing and adding refrigerant oil

1. Change the compressor - DO NOT recharge the oil as the compressor itself is

already charged.

2. Change the condenser .... add 50cc

3. Change the evaporator .... add 50cc

4. When the refrigerant is replaced .... add 30cc oil.

5. After vacuum is completed, the oil is filled through the high pressure side.

6. In the event of a refrigerant leak, generally it is not necessary to add oil

(unless the oil has leaked significantly).

Put approximately 10cc oil into a transparent container and test it.

4-3 Refrigerant Oil Specifications

Normal

Overheat

Motor Damage

Condition of

Refrigerant Cycle

Color

Light Yellow

Brown Color

Dark Brown

No Odor

Pungent Oil

Odor

Remarks

Return with the system

Oil Change

Condition of Oil

Model Oil Specification Oil Change

AW05B0LA(AW0519) SONTEX 200LT 280CC
