Minimum Cross-Sectional Area of Power Cable and Interconnection cord:

Rated Current

of Appliance (A)

Nominal Cross-

Sectional Area

(mm

)

＞3 and ≤ 6

0.75

＞6 and ≤10

＞10 and ≤16

1.5

＞16 and ≤25

2.5

＞25 and ≤32

＞32 and ≤40

 The size of the interconnection cord, power cable, fuse, and switch needed is determined

by the maximum current of the unit.

 The maximum current is indicated on the nameplate located on the side panel of the unit.

Refer to this nameplate to choose the right cable, fuse, or switch.

Requirements for operations at raised height:

 When carrying out installation at 2 m or higher above the base level, safety belts must be

worn and ropes of sufficient strength be securely fastened to the outdoor unit, to prevent

falling that could cause personal injury or death as well as property loss.

Grounding Requirements:

 The air conditioner is the type I electrical appliance and must ensure a reliable grounding.

 Do not connect the grounding wire to a gas pipe, water pipe, lightning rod, telephone line,

or a circuit poorly grounded to the earth.

 The grounding wire is specially designed and shall not be used for other purpose, nor shall

it be fastened with a common tapping screw.

Others:

The model and rating value of the fuse shall be subject to the silkscreen on corresponding

controller or fuse sleeve.
