Philips P8BLK [3/3] Charge check battery level
![Philips P8BLK [3/3] Charge check battery level](/views2/1094175/page3/bg3.png)
Charging ongoing: The four power LEDs light up white alternately. Charging complete: All four power LEDs light up
white.
To check the battery level, touch the speaker. The power LEDs light up. The red light flashes when the battery is low.
When music plays from the speaker through an MP3 link cable, increase the volume on the audio player if necessary.
Cuando la música se reproduce desde el altavoz a través de un cable de conexión MP3, aumente el volumen en el
reproductor de audio sies necesario.
Lorsque la musique est diffusée depuis l'enceinte via un câble MP3Link, augmentez le volume sur le périphérique audio,
sinécessaire.
Charge Check battery level
Play
AUX IN
100%
75%
50%
25%
10%
Specifications
EN
ES
FR
EN
EN
Amplifier
Rated output power: 2 X 10 RMS (THD= 1%)
Signal to noise ratio: > 65 dB
AUDIO-IN: 0.6 V RMS 22 kOhm
Bluetooth
Standard: Bluetooth Standard Version 2.1 + EDR
Frequency band: 2.402 ~ 2.480 GHz ISM Band
Range: 10 m (free space)
General information
AC power
Philips OH-1028E1502000U
Input: 100-240 V~ 50/60 Hz, 800 mA MAX
Output: 15 V DC, 2 A
Built-in battery
Model no : ICR18650X3
Cell Model: ICR18650
Rating: 2200 mAh, 11.1V
Operation Power Consumption: <42 W
Charging
maximum 1000 mA for USB, 600 mA for power adapter
(power off)
Dimensions
Main Unit (W x H x D): 287 mm x 124 mm x 51 mm
Weight
Main Unit: 0.965 kg
EspecificacionesTechnische Daten Caractéristiques techniques
Verstärker
Ausgangsleistung: 2 X 10 RMS (THD= 1%)
Signal-/Rauschverhältnis: > 65 dB
AUDIO IN: 0.6 V RMS 22 kohm
Bluetooth
Standard: Bluetooth-Version: 2.1+EDR
Frequenzband: 2,402~2,480GHz ISM-Band
Reichweite: 10m (freier Raum)
Allgemeine Informationen
Netzspannung
Philips OH-1028E1502000U
Eingangsleistung: 100 bis 240V~, 50/60Hz; 800mA MAX
Ausgangsleistung: 15VDC, 2A
Integrierter Akku
Modellnummer: ICR18650X3
Batteriemodell: ICR18650
Leistung: 2200mAh, 11,1V
Betriebs-Stromverbrauch: <42 W
Laden
maximal 1000mA für USB, 600mA für Netzteil
(Abgeschaltet)
Abmessungen
Hauptgerät (BxHxT): 287mm x124mmx51mm
Gewicht
Hauptgerät: 0,965kg
Amplificador
Potencia de salida nominal:2 X 10 RMS (THD= 1%)
Relación señal/ruido: > 65 dB
AUDIO IN:0.6 V RMS 22kohmios
Bluetooth
Estándar: Versión estándar de Bluetooth 2.1 + EDR
Banda de frecuencia: Banda ISM de 2,402~2,480GHz
Alcance: 10m (espacio libre)
Información general
Alimentación de CA
Philips OH-1028E1502000U
Entrada: 100-240V~, 50/60Hz, 800mA máximo
Salida: 15V de CC, 2A
Batería integrada
Número de modelo: ICR18650X3
Modelo de batería: ICR18650
Clasificación: 2200mAh, 11,1V
Consumo de energía en funcionamiento <42 W
Carga
máxima de 1000mA para USB, 600mA para adaptador de
alimentación (apagado)
Dimensiones
Unidad principal (ancho x alto x profundo): 287mm x
124mm x 51mm
Peso
Unidad principal: 0,965kg
Amplificateur
Puissance de sortie nominale: 2 X 10 RMS (THD= 1%)
Rapport signal/bruit: > 65 dB
AUDIO IN:0.6 V RMS 22 kOhm
Bluetooth
Standard: Norme Bluetooth version2.1 + EDR
Fréquence de transmission: Bande ISM 2,402 ~ 2,480GHz
Portée:10m (sans obstacle)
Informations générales
Alimentation par secteur
Philips OH-1028E1502000U
Entrée: 100-240V~ 50/60Hz, 800mA MAX
Sortie: 15VCC, 2A
Batterie intégrée
Numéro de modèle: ICR18650X3
Modèle cellule: ICR18650
Puissance: 2200mAh, 11,1V
Consommation électrique en mode de fonctionnement
<42 W
Charge
max. 1000mA pour l'USB, 600mA pour l'adaptateur
secteur (hors tension)
Dimensions
Unité principale (IxHxP): 287x124x51mm
Poids
Unité principale: 0,965kg
Ladevorgang läuft: Die vier Betriebsanzeigen leuchten abwechselnd weiß auf. Ladevorgang beendet: Alle vier
Betriebsanzeigen leuchten weiß auf.
Carga en curso: los cuatro LED de alimentación se iluminan alternativamente. Carga completa: los cuatro LED de
alimentación se iluminan en blanco.
Charge en cours: les quatrevoyants d'alimentation s'allument alternativement en blanc. Charge terminée: les quatre
voyants s'allument en blanc.
Um den Akkuladestand zu überprüfen, berühren Sie den Lautsprecher. Die Betriebsanzeige leuchtet auf.Die rote
Anzeige blinkt, wenn der Akkuladestand niedrig ist.
Para comprobar el nivel de la batería, toque el altavoz. Los LED de alimentación se iluminan. El piloto rojo parpadea
cuando la batería se está agotando.
Pour vérifier le niveau de charge de la batterie, touchez l'enceinte. Le voyant d'alimentation s'allume. Le voyant
clignote en rouge lorsque la batterie est faible.
Laden Carga Mise en charge
Überprüfen des Akkuladestands
Comprobación del nivel de la batería Vérification du niveau de charge de la batterie
DE
ES
FR
DE
ES
FR
Wenn die Musik vom Lautsprecher über ein MP3 Link-Kabel wiedergegeben wird, erhöhen Sie ggf. die Lautstärke
desAudio-Players.
Wiedergabe LectureReproducción
DE
Содержание
- Check battery level 1
- Comprobación del nivel de la batería vérification du niveau de charge de la batterie 1
- P8 the function is unavailable for p8 1
- Überprüfen des akkuladestands 1
- Besuchen sie www philips com support für support informationen 2
- Go to www philips com support for support information 2
- Mise sous tension et connexion encendido y conexión einschalten verbinden 2
- Rendez vous sur www philips com support pour des informations relatives à l assistance 2
- Switch on connect 2
- Vaya a www philips com support para obtener información de asistencia 2
- Wiedergabe lecture reproducción 2
- Www philips com support 2
- Zurücksetzen restaurar réinitialisation 2
- Allgemeine informationen 3
- Amplificador 3
- Amplificateur 3
- Amplifier 3
- Bluetooth 3
- Charge check battery level 3
- Comprobación del nivel de la batería vérification du niveau de charge de la batterie 3
- Especificaciones technische daten caractéristiques techniques 3
- General information 3
- Información general 3
- Informations générales 3
- Laden carga mise en charge überprüfen des akkuladestands 3
- Specifications 3
- Verstärker 3
- Wiedergabe lecture reproducción 3
