Important

Read these instructions for use carefully before using the appliance and save them for future

reference.

◗ Only use Philips s-bag` double-layer paper dustbags or the cotton dustbag provided.

◗ Never suck up water or any other liquid. Never suck up ashes until they are cold.

◗ When the vacuum cleaner is used to suck up fine dust, the pores of the dustbag may become

clogged, causing the passage of air through the dustbag to become obstructed.As a result, the

'dustbag full' indicator will indicate that the dustbag needs to be replaced, even though the

dustbag is not full at all.

◗ Never use the appliance without the Motor Protection Filter.This could damage the motor

and shorten the life of the appliance.

◗ If the mains cord of this appliance is damaged, it may only be replaced by Philips or a service

centre authorised by Philips in order to avoid hazardous situations.

1 Noise level: Lc= 80 dB(A)

Connecting accessories

Hose

1 To connect the hose, push it into the appliance and turn it clockwise (fig. 1).

To disconnect the hose, turn it anticlockwise and pull it out of the appliance.

2 Connect the tubes to each other and to the handgrip by inserting the narrow section into

the wider section while turning it a little.The tube with the clip is the lower tube (fig. 2).

You can connect the accessories in the same way.

Disconnect the accessories and tubes by pulling them and turning them a little.

Telescopic tube (specific types only)

1 Adjust the tube to the length you find most comfortable during vacuum cleaning (fig. 3).

Combi nozzle

The combi nozzle can be used on either carpets (with the brush strips folded in) or hard floors

(with the brush strips folded out):

1 Push the rocker switch on top of the combi nozzle with your foot to make the brush strip

for cleaning hard floors come out of the nozzle housing (fig. 4).

2 Push the rocker switch on the other side to make the brush strip disappear into the housing

(fig. 5).

Crevice nozzle

1 The crevice nozzle can be found in the special storage compartment (fig. 6).

Using the appliance

Adjusting the suction power

1 You can adjust the suction power by means of the slide on the handgrip (specific types only)

(fig. 7).

2 You can adjust the suction power by means of the electronic suction power control (specific

types only) (fig. 8).

ENGLISH6
