Philips FC8388 [7/58] English

Carrying the appliance

1 To carry the appliance, put the handle in upright position (fig. 9).

Storage

1 Put the appliance in upright position and attach the lower tube to the appliance by means of

the clip (fig. 10).

The clip can be slid along the tube to adjust its height.

Replacing the dustbag

◗ Replace the dustbag as soon as the 'dustbag full' indicator has changed colour permanently.

1 Switch the appliance off and open the cover (fig. 11).

2 Push the dustbag holder backwards (fig. 12).

3 Lift the dustbag out of the compartment by pulling the cardboard lug upwards.This causes

the dustbag to become sealed (fig. 13).

4 Slide the cardboard front of the new dustbag into the two grooves of the dustbag holder.

Press it down as far as possible (fig. 14).

5 Pull the dustbag holder forwards until you hear a click.You cannot close the cover if no

dustbag has been inserted (fig. 15).

Philips s-bag` paper dustbags are available under type number FC8021 (883802101010).

◗ If provided, you can use the cotton dustbag instead of paper dustbags.

The cotton dustbag can be used and emptied repeatedly.

For removing and inserting the cotton dustbag, simply follow the instructions for replacing paper

dustbags.

To empty the cotton dustbag:

1 Remove the clip by sliding it off the dustbag sideways.

2 Undo the metal hooks.

3 Shake out the contents.

4 Close the dustbag by fastening the metal hooks and sliding the clip back onto the bottom

edge of the dustbag.

Philips cotton dustbags are available under type number FC8020 (432200493291).

Filter replacement

AFS Micro Filter

Replace the AFS Micro Filter every 6 months.

The AFS Micro Filter will remove a large part of the smallest particles from the exhaust air.

1 Detach the filter holder and remove the filter (fig. 16).

2 Place the sides (1, 2) and the bottom edge (3) of the new filter properly behind the ridges of

the holder (fig. 17).

3 Put the holder back into the vacuum cleaner by first hooking the bottom edge of the holder

into the appliance (1) and then pushing the holder towards the appliance (2) until it snaps

home (fig. 18).

Make sure the filter holder has been placed properly.

ENGLISH 7
