Connecting peripheral equipment The television has 1 external socket situated at the back of the set EXT1 and sockets on the side Press the AV key on the remote control to display Source List and select TV or peripheral equipment connected to EXT1 AV SVHS PC or HD The EXT socket has audio CVBS RGB inputs and audio CVES outputs The side connections has audio inputs CVBS S VHS inputs headphone out Video recorder DVD R Carry out the connections shown opposite using a good quality euroconnector cable If your video recorder does not have a euroconnector socket the only connection possible is via the aerial cable You will therefore need to tune in your video recorder s test signal and assign it programme number 0 refer to manual store p 5 To reproduce the video recorder picture press 0 key Video recorder DVD R with decoder Connect the decoder to the second euroconnector socket of the video recorder or DVD R You will then be able to record scrambled transmissions W W J 11
