Assembling vacumm cleaner
Carpet and floor nozzle (1)
Push the nozzle into the telescopic pipe.
Telescopic pipe (2)
• Push telescopic pipe firmly into hose handle
• Grasp the spring latch to expand.
• Pull out the pipe to desired length.
Connecting the hose to the vacuum
cleaner Monter (3)
Push the fitting pipe on the flexible hose into
the attachment point on the vacuum cleaner.
To remove the flexible hose from the vacuum
cleaner, press the button situated on the fitting
pipe, then pull the fitting pipe out of the
vacuum cleaner.
Operating vacuum cleaner
How to operate (4)
• Pull out the power cord to the desired length
and plug into the socket.
• Place the control knob of the hose handle to
the required position.
• To turn off, slide control knob to OFF position.
• Press the cord reel button to rewind the
power cord after use.
Park mode (5)
• To store during vacuuming, for example to
move a small piece of furniture or a rug, use
park mode to support the flexible hose and
nozzle.
- Slide the hook on the nozzle into the slot on
the side of vacuum cleaner.
Storage (6)
• When you have switched off and unplugged
the vacuum cleaner, press the cord reel
button to automatically rewind the cord.
• You can store your vacuum cleaner in a
vertical position by sliding the hook on the
nozzle into the slot on the underside of the
vacuum cleaner.
Using carpet and floor nozzle
Carpet and floor nozzle (Depend on
model) (7)
• The 2 position nozzle
This is equipped with a pedal which allows
you to alter its position according to the type
of floor to be cleaned.
Hard floor position (tiles, parquet floors...).
Press on the pedal to lower the brush.
Carpet or rug position.
Press on the pedal to lift the brush up.
Angle Nozzle for Device Protection
(Depend on model) (8)
• You can perform cleaning at any place like
corner or crevice since revolution of the
suction hole is free.
Hard Floor Nozzle (Depend on model) (9)
• Efficient cleaning of hard floors (wood,
linoleum, etc)
Using All Floor nozzle and mini
turbine nozzle
All Floor nozzle (Depend on model) (10)
• The 2 position nozzle
This is equipped with a pedal which allows
you to alter its position according to the type
of floor to be cleaned.
• Carpet or rug position
Press the pedal ( ), then brush will rotate
• Hard floor position
Press the pedal ( ), then brush will stop
rotating.
Cleaning All Floor nozzle
• Open the cover by pulling the hook.
• Clean the hole and brush of the nozzle.
Mini turbine nozzle (Depend on model) (11)
• Mini turbine is used for stairs and other hard
to reach places.
• To clean the mini turbine nozzle, remove the
nozzle cover:
Remove 2 screws on the bottom and take
mini turbine nozzle cover off as shown.
• Frequently clean and remove hair, string, and
lint build-up in the brush area.
Failure to do so could damage to mini turbine
nozzle.
User's guide for turbine nozzle
Turbine Nozzle (Depend on model) (12)
• Cleaning turbine brush nozzle.
• Press the button on the rear side of the nozzle
to separate the air cover.
• Use the dusting brush & crevice tool to vacuum
clean the brush and fan.
Using accessory nozzles(Depend on model)
Upholstery nozzle (13)
Upholstery nozzle is for vacuuming upholstery,
mattresses etc.
Dusting brush (14)
Dusting brush is for vacuuming picture frames,
furniture frames, books and other irregular
surfaces.
ENGLISH
- 23 -
