Sencor SVC 730GR ALTO [4/8] Vacuum cleaner

Vacuum cleaner

SVC 730RD / SVC 730GR

05/2012

ASSEMBLY

Inserting the hose 6 into the air suction hole on the vacuum cleaner.

Press the safety button on the hose end and insert the hose end into the air suction hole on the

vacuum cleaner until you hear „click". The hose is now secured in correct position.

Place the holder 7 on the telescopic tube 9

Make sure to install the holder on the wider part of the telescopic tube.

Install the ﬂ oor inlet nozzle 0 on the telescopic tube 9

Make sure to install the ﬂ oor nozzle on the narrower part of the telescopic tube.

Adjust the length of the telescopic tube 9 as needed.

Adjust the length of the telescopic tube as follow: Move and hold the button on the tube forward as

shown by arrows and adjust the length of the tube as needed. Release the button and move the tube

little bit forward until you hear „click". The telescopic tube is now securely set in position.

USING YOUR VACUUM CLEANER

Connecting your vacuum cleaner to power source - wall outlet

Pull the plug of the supply cable from the vacuum cleaner until the desired length of the cable is out

of the appliance. Insert the plug to the wall outlet.

Warning:

Yellow marking on the supply cable tells you that the cable is close to its end. Do not pull the

cable more than to the red marking.

Adjusting the ﬂ oor inlet nozzle 0 according to the ﬂ oor surface.

You may set the inlet nozzle according to the ﬂ oor surface by adjusting the inlet ﬂ ap:

• If you want to vacuum carpets, close the bristles of the inlet inside the inlet nozzle, by turning

the ﬂ ap accordingly.

• If you want to vacuum hard and smooth surface, move the bristles out of the nozzle, by turning

the ﬂ ap accordingly.

Turning your vacuum cleaner on and off

To switch your machine on and off, press the START / STOP button 1 on the vacuum cleaner body.

Adjusting the suction strength 8

The suction strength may be adjusted by moving the rider on the appliance body ( small range) or by

the moveable rider 6 on the hose handler.

Tip:

If the hose holder 7 on the hose 6 gets clogged during vacuuming, disconnect it from the

telescopic tube9 and also disconnect the hose6 from the vacuum cleaner body. Then place the

holder 7 inside the suction hole on the vacuum cleaner body and vacuum the stuck dirt out.

Temporary interruption of the vacuuming process

If you want to stop the vacuuming process temporarily, place the telescopic tube 9 in the parking

position on the rear of your appliance, using the notch on the ﬂ oor inlet nozzle0

Warning:

Do not move the appliance from place to place if the hose is in the parking position! You may

break the parking position holder!
