Elenberg JM-5032 [13/16] Before use

switch to OFF, then remove plug from wall outlet.

• Always make sure juicer cover is locked securely in place before

motor is turned on, Do not unlock the cover while the juicer is in

operation.

• Be sure to turn switch off after each use of your appliance. Make

sure the motor stops completely before disassembling.

• For safety reasons, the appliance is equipped with a safety in-

terlock system which prevents it from operating unless the juice

extractor or the blender is correctly ﬁtted.

• Wash all detachable parts before using it.

• Max operating time: 1 min, resting time: 1 min.

SAVE THESE INSTRUCTIONS

• Remove all packaging, including the packaging between the bot-

tom of the chute and the grating sieve.

• Before using your juice extractor and blender for the ﬁrst time or

following periods prolonged storage, you should dismantle and

clean it to remove dust etc. (See cleaning section)

HOW TO ASSEMBLE

1. Put the pulp container on the driving unit/

main housing at 30 degree and rotate it

clockwise until its lock in place. (Fig 2)

2. Lay the grating sieve inside the pulp con-

tainer and rotate it clockwise until it catch-

es on the drive spindle.

3. Put the transparent top cover on, press

down the two lock buttons with both hands

until you hear it snap into place. (Fig 1) Al-

ways close cover after pulp container is as-

sembled.

4. The juice extractor is equipped with a safety

interlock system, it won’t operate unless the

unit is properly ﬁtted.

5. Put a juice container, it can be either a cup,

mug under the juice outlet in the middle of

the front.

6. Pull the non-drip valve down and make sure

it is always open when the unit is switch on.

7. Replace the fruit pusher.

BEFORE USE

JUICE EXTRACTOR
