Ø Do not grind hard food such as

bones, nuts, etc.

Ø Do not grind ginger and other

materials with hard fiber.

Ø Continuous running of meat

grinder should be not more

than 10 minutes with the fol-

lowing 10 minutes interval for

motor cooling.

Ø Reverse function is prohibited

while the appliance is operating

(For example switch “ON” knob

to “R” knob or on the contra-

ry), wait at least one minute

until grinder has come to a

complete stop, otherwise it

may cause an abnormal noise,

vibration or a transitory electric

spark in the appliance. It could

result easily damage to appli-

ance and make a user fright-

ened.

Ø After use, there would be a lit-

tle food left in the grinder

head. This is normal. There

might be a bit of black metal

powder adhering to the food

ground in the end. Please pick

them out and throw away, do

not eat them.

Ø To avoid jamming, do not force

to operate the unit with exces-

sive pressure.

Ø When the circuit breaker acti-

vates, do not switch on.

Ø Never try to replace the parts

and repair the unit by yourself.

Ø Service life – 2 years

FOR THE FIRST TIME

Ø Check that voltage indicated on

the rating label corresponds

the mains voltage in your

home.

Ø Wash all parts (except body) in

warm soapy water.

Ø Before plugging in, ensure the

“ON/OFF/ Reverse” switch is

turned to "OFF" position.

INSTRUCTION FOR USE

ASSEMBLING

Holding the head and insert it in the

inlet with one hand, place the locking

knob into the hole on the side of the

motor housing, tighten it clockwise to

secure the head (fig.2)

Place the feed screw into the head, long

end first, by turning the feed screw

slightly until it is set into the motor

housing (fig.3).

Place the cutting blade onto the feed

screw shaft with the blade facing the

front as illustrated (fig.4). If it is not

fitted properly, meat will not be ground.

Place the desired cutting plate next to

the cutting blade, fitting protrusions in

the slots (fig.5).

Support or press the centre of the cut-

ting plate with one finger then screw the

fixing ring until tight with another hand

(fig.6). Do not over tighten.

Place the hopper plate on the head and

fix into position.

Locate the unit on a firm place.

The air passage at the bottom and the

side of the motor housing should be

kept free and not blocked.

MINCING MEAT

Cut all foods into pieces (Sinewless,

boneless and fatless meat is recom-

mended, approximate size: 20 mm x 20

mm x 60 mm) so that they fit easily into

the hopper opening.

Plug in and turn the “R / ON” switch to

"ON" position, then turn the “ON/OFF/

Reverse” switch to "ON" position.

Feed foods into the hopper plate. Use

only the food pusher (fig.7).

After use switch the unit off and unplug

it from the power supply.

REVERSE FUNCTION

In case of jamming switch the appliance

off by turning the “R / ON” switch to

"R" position and “ON/OFF/ Reverse”

switch to "R" position.

Feed screw will be rotating in the oppo-

site direction, and the head will get

empty.

If it doesn't work, switch the unit off

and clean it.

MAKING KEBBE

RECIPE

STUFFING

Mutton 100g

Olive oil 1 tablespoon

Onion (cut finely)1 tablespoon

Spices to your taste

Salt to your taste

Flour 1 tablespoon

Mince mutton once or twice.

Fry onion until brown and add minced

mutton, all spice, salt and flour.

OUTLET COVER

Lean meat 450 g

Flour 150-200g

Spices to your taste

Nutmeg (cut finely) 1

Powdered red pepper to your taste

Pepper to your taste

- Mince meat three times and mix all

ingredients togeth-

er in a bowl. More

meat and less flour

for outlet cover

creates better con-

sistency and taste.

- Grind the mixture

three times.

-Disassemble by

reversing the steps

from 5-3 to remove

the cutting plate

and cutting blade.

- Place kebbe at-

tachments onto the

feed screw shaft

together, fitting

protrusions in the

slots (fig.8).

- Screw fixing ring

into place until

tight. Do not over

tighten (fig.9).

- Make the cylindri-

cal outlet cover

(fig.10)

- Form kebbe as

illustrated below and deep fry.

MAKING SAUSAGE

Before starting please assemble sausage

attachment as per following (fig.11)

CLEANING AND MAINTENANCE

DISASSEMBLING

Make sure that the motor has stopped

completely.

Disconnect the plug from the power

outlet.

Disassemble by reversing the steps

from 6-1 pictures.

If the fixing ring

is not easily re-

moved by

hands, please

use

tools（fig.12）.

To remove the

cutting plate

easily, place a

screwdriver be-

tween the cut-

ting plate and

the head as il-

lustrated and lift

it up (fig.13).

CLEANING

Remove meat, etc. Wash each part in

warm soapy water.

A bleaching solution containing chlorine

will discolor aluminum surfaces.

Do not immerse the motor housing in

water, but only wipe it with a damp

cloth.

Thinners and petrol will crack or change

the color of the unit.

Wipe all the cutting parts by vegetable

oil-wet cloth.

Specification

Rated power: 400W

Maximum power: 800 W

Working voltage: 220-230 V

Rated сurrent 1,8 А

Working frequency:50 Hz

Set

Meat grinder 1

Sausage attachment 1

Kebbe attachment 1

Instruction manual &

Warranty book 1

Package 1

Environment friendly disposal

You can help protect the environment!

Please remember to re-

spect the local regula-

tions: hand in the non-

working electrical equip-

ments to an appropriate

waste disposal centre.

The manufacturer re-

serves the right to

change the specification and design

of goods.
