Replacement

A worn or damaged cutting unit should only be replaced with an

original Philips cutting unit.

1 Open the cutting unit by applying pressure in the centre and then

remove it by pulling it upwards (fig. 9).

2 Place the two lugs of the new cutting unit into the guiding slots

and push the unit back onto the appliance (fig. 10).

Environment

The built-in rechargeable battery contains substances which may

pollute the environment.

Remove the rechargeable battery when you discard the appliance.

Do not throw the battery away with the normal household waste but

dispose of it at an official collection point.

You can also take the appliance to a Philips service centre, which will

remove the battery for you and will dispose of it in an environmentally

safe way.

1 Disconnect the appliance from the mains and let the appliance

run until the motor stops.

2 Open and remove the cutting unit (See chapter 'Cleaning').

3 Undo the screws and remove the metal clip by means of a

screwdriver (fig. 11).

4 Remove the top part by pulling it off the appliance (fig. 12).

5 Turn the zoom ring until the comb holder is in its highest

position (fig. 13).

6 Then use some force to turn the zoom ring still further until the

comb holder comes loose from the appliance (fig. 14).

7 Separate the two housing parts by means of a screwdriver (fig.

15).
